COUNTER
OR SINK
1-3/8”
HOLE
F
G
E
REQUIRED TOOLS:
Adjustable Wrench
A
B
C
D
1.
2.
3.4.
5.
6.8.7.
SOAP/LOTION DISPENSER INSTALLATION
TRADITIONAL Models # 4055, 4055E, 4060, 4060E
BEFORE YOU BEGIN YOUR INSTALLATION:
Pull and remove
spout (A) from
dispenser body
(B). Remove
clamp nut (C)
from threaded
shroud (D).
Fit dispenser body through 1-3/8”
hole on counter or sink. (No plumbers
putty is required. O-ring seals base).
Thread the clamp nut. Tighten nut
snug to underside of sink or counter.
Thread bottle (E) into bottom of
dispenser shroud.
Slide red tubing (F)
into tube tting (G)
at bottom of spout.
From above the
counter, pour
soap through
dispenser body
into plastic
bottle. Do not
overll.
Insert open end
of red tubing
down through
dispenser and
into plastic
bottle.
Pump spout a
few times to get
soap or lotion
owing.
41180 Raintree Court • Murrieta, CA 92562
1-888-304-0660 • 951-304-0520
www.waterstoneco.com
VEN-038-SOAP Rev. D
Push down on
spout to secure
over white O-rings.
