Sida 1/8
Page1of8
©Copyright 2015 WESCO Industrial Products, Inc. Specifications subject to change. Not responsible for errors or omissions.
TABLE OF CONTENTS
1 General Information ......................................................................................................... 2
1.1 Description.............................................................................................................. 2
1.2 Specifications.......................................................................................................... 2
2 Assembly & Adjustment..................................................................................................... 2
3 Troubleshooting................................................................................................................. 4
4 Fork Frame Information..................................................................................................... 5
4.1 Fork Frame Parts Diagram...................................................................................... 5
4.2 Fork Frame Parts List.............................................................................................. 6
5 Pump Assembly Information.............................................................................................. 7
5.1 Pump Assembly Parts Diagram............................................................................... 7
5.2 Pump Assembly Parts List....................................................................................... 8
WESCOINDUSTRIALPRODUCTS,INC
InstructionManual
ManualNon‐TelescopingHighLiftTruck
PartNumber: 272462&272463
Note: Operator MUST read and understand these operating instructions before
using this Truck.
Page2of8
©Copyright 2015 WESCO Industrial Products, Inc. Specifications subject to change. Not responsible for errors or omissions.
Manual Non-Telescoping High Lift Truck
(Part # 272462 & 272463)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HIGH LIFT
TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
1. GENERAL INFORMATION
1.1 DESCRIPTION
Thank you for purchasing a Wesco Manual Non-Telescoping High Lift Truck. This pallet truck is
designed for transporting and horizontal lifting. The manual high lift trucks feature a one year pump
warranty, a 180° steering arc and a loop handle with inner hand control.
1.2 SPECIFICATIONS
Model 272462 272463
Capacity 2,200 lbs 2,200 lbs
Weight 275 lbs 300 lbs
Fork Lowered Height 3.3” 3.6”
Fork Raised Height 31.5” 31.5”
Single Fork Width 6.5” 6.5”
Fork Length 44.5” 44.5”
Overall Width 21” 27”
Overall Length 56” 56”
Overall Height 48.5” 48.5”
Telescoping No No
Steering & Load Wheels Polyurethane Polyurethane
Materials and specifications are subject to change without notice.
2. ASSEMBLY & ADJUSTMENT
1) Screw (Item 132)
- To prevent oil-leaking from oil tank during transportation the air screw (Item 132) is replaced with
oil-sealing screw in the factory. Upon reaching its destination and before operation the air screw
must be inserted back in place. Screw out the Oil-sealing screw, then screw in the air screw.
2) Handle
- During transportation, the handle is disassembled from the truck and packed separately. It must
be properly reassembled before operation of the unit.
