Note: Operator MUST read and understand these operating instructions before using this Truck.
TABLE OF CONTENTS
1 General Information....................................................................................................................................... 2
1.1 Description.......................................................................................................................................... 2
1.2 Specifications...................................................................................................................................... 2
2 Assembly & Adjustment................................................................................................................................. 2
3 Operation....................................................................................................................................................... 3
4 Safety Information.......……........................................................................................................................... 3
5 Trouble Shooting........................................................................................................................................... 4
6
Hydraulic Circuit / Electric Wiring Diagram.................................................................................................... 5
6.1 Hydraulic Circuit Diagram.................................................................................................................... 5
6.2 Electric Wiring Diagram....................................................................................................................... 5
7 Fork Frame Information................................................................................................................................. 6
7.1 Fork Frame Parts Diagram.................................................................................................................. 6
7.2 Fork Frame Parts List..................................................................................................................... ..... 7
8 Electric Control Assembly Information........................................................................................................... 8
8.1 Electric Control Assembly Diagram
(Units Manufactured Before 08/2010 or After 06/2015)
........... 8
8.2 Electric Control Assembly Parts List
(Units Manufactured Before 08/2010 or After 06/2015)
.......... 9
8.3 Electric Control Assembly Diagram
(Units Manufactured Between 08/2010 & 06/2015)
................... 10
8.4 Electric Control Assembly Parts List
(Units Manufactured Between 08/2010 & 06/2015)
................. 11
9 Pump Assembly Information.......................................................................................................................... 12
9.1
Pump Assembly Diagram (Units Manufactured Before 08/2010 or After 06/2015)
........................... 12
9.2 Pump Assembly Parts List
(Units Manufactured Before 08/2010 or After 06/2015)
......................... 13
9.3
Pump Assembly Diagram (Units Manufactured Between 08/2010 & 06/2015).................................. 14
9.4 Pump Assembly Parts List
(Units Manufactured Between 08/2010 & 06/2015)
................................ 15
10 Handle Information........................................................................................................................................ 16
10.1 New Style Handle Diagram
(4 Wire With Up/Down Switch Inside)
.................................................... 16
10.2 New Style Handle Parts List
(4 Wire With Up/Down Switch Inside)
................................................... 17
10.3 Old Style Handle Diagram
(3 Wire With Up/Down Switch On Top)
................................................... 18
10.4 Old Style Handle Parts List
(3 Wire With Up/Down Switch On Top)
.................................................. 19
WESCOINDUSTRIALPRODUCTS,LLC
InstructionManual
ElectricHighLiftTruck
PartNumber: 272937&272939
Page2of19
© Copyright 2019 WESCO Industrial Products, LLC. Specifications subject to change. Not responsible for errors or omissions.
Electric High Lift Truck
(Part # 272937 & 272939)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HIGH LIFT
TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
WARNING: The battery in this product contains lead. The State of California under
Proposition 65 has determined that exposure to lead is known to cause cancer or birth
defects or other reproductive harm. Please wash hands after use.
1. GENERAL INFORMATION
1.1 DESCRIPTION
Thank you for purchasing a Wesco Electric High Lift Truck. This pallet truck is designed for
transporting and horizontal lifting. The electric high lift trucks feature a one year pump warranty and a
battery powered hydraulic lift system that is operated with fingertip controls. It can greatly reduce labor
and increase working efficiency and is an efficient tool for various work environments. It has various
uses such as a work table, a loading and unloading table, and a tool transporter.
1.2 SPECIFICATIONS
Model 272939 272937
Capacity 3,000 lbs 3,000 lbs
Weight 344 lbs 347 lbs
Fork Lowered Height 3.3” 3.3”
Fork Raised Height 31” 31”
Single Fork Width 6.5” 6.5”
Fork Length 45” 45”
Overall Width 21” 27”
Overall Length 60” 60”
Overall Height 48.5” 48.5”
Steering & Load Wheels Polyurethane Polyurethane
Materials and specifications are subject to change without notice.
2. ASSEMBLY & ADJUSTMENT
1) Remove all packing materials carefully.
2) Insert handle (102X) into the socket of cylinder (160) then lock it with pin (108) and two snap rings
(109). Swing handle up and down verify it moves freely. Finally put on spring (105).
3) Open the electrical control case by removing the cover (255). Insert switch wire and plug (184)
hanging down from handle (102) into socket (221) in the case. Insert two fuses of 5 Amp (277) into
two sockets F
1
/F
2
.
4) Check the electrical device and elements in the case to make sure there are no loose, dropped
down or broken items.
5) Check oil pipes in the hydraulic system to see if they are screwed on tightly. Open cover (217) to
see if oil is sufficient.
6) Observe the electrical device and elements in the case while pushing the Up-Button (197X) |^| on
top of handle (102X) intermittently to lift the fork. If there are no abnormal effects, continue to push
the Up-Button to lift the fork to its highest position. Then push the Down-Button (197X) |^| to release
the fork to its lowest position steadily.
NOTE: Repeat Step 6 3-4 times to it full travel in order to release possible air in the hydraulic
system and verify the unit is working properly.
7) Close the case with the cover (255) and screw it tightly with screw (256).
