TABLE OF CONTENTS
1 General Information ......................................................................................................... 2
1.1 Description.............................................................................................................. 2
1.2 Specifications.......................................................................................................... 2
2 Assembly & Adjustment..................................................................................................... 2
3 Trouble Shooting............................................................................................................... 4
4 Fork Frame Information..................................................................................................... 5
4.1 Fork Frame Parts Diagram...................................................................................... 5
4.2 Fork Frame Parts List.............................................................................................. 6
5 Pump Assembly Information.............................................................................................. 7
5.1 Pump Assembly Parts Diagram............................................................................... 7
5.2 Pump Assembly Parts List....................................................................................... 8
6 Handle Assembly Information............................................................................................ 10
6.1 Handle Assembly Parts Diagram............................................................................. 10
6.2 Handle Assembly Parts List..................................................................................... 11
WESCOINDUSTRIALPRODUCTS,INC
InstructionManual
TelescopingManualHighLiftTruck
PartNumber:272754,272755,272975&272976
Note: Operator MUST read and understand these operating instructions before
using this Truck.
Page2of11
© Copyright 2015 WESCO Industrial Products Inc. Specifications subject to change. Not responsible for errors or omissions
Telescoping Manual High Lift Truck
(Part # 272754, 272755, 272975 & 272976)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HIGH LIFT
TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
1. GENERAL INFORMATION
1.1 DESCRIPTION
Thank you for purchasing a Wesco Telescoping Manual High Lift Truck. This pallet truck is
designed for transporting and horizontal lifting. The trucks feature a 180° steering arc, loop handles
with inside hand control and a 1 year pump warranty.
1.2 SPECIFICATIONS
Model 272754 272755 272975 272976
Capacity 2,200 lbs 2,200 lbs 3,300 lbs 3,300 lbs
Weight 228 lbs 219 lbs 260 lbs 276 lbs
Fork Lowered Height 3.3” 3.6” 3.6” 3.6”
Fork Raised Height 31.5” 31.5” 31.5” 31.5”
Single Fork Width 6.5” 6.5” 6.5” 6.5”
Fork Length 44.5” 44.5” 43” 43”
Overall Width 27” 21” 20” 27”
Overall Length 63” 63” 63” 63”
Overall Height 48.5” 48.5” 48.5” 48.5”
Telescoping Yes Yes Yes Yes
Steering & Load Wheels Polyurethane Polyurethane Polyurethane Polyurethane
Materials and specifications are subject to change without notice.
2. ASSEMBLY & ADJUSTMENT
1) Screw (Item 158)
- To prevent oil-leaking from oil tank during transportation the air screw (Item 158) is replaced with
oil-sealing screw in the factory. Upon reaching its destination and before operation the air screw
must be inserted back in place. Screw out the Oil-sealing screw, then screw in the air screw
which the pump housing (Item 160) is hung.
2) Handle
- During transportation, the handle is disassembled from the truck and packed separately. It must
be properly reassembled before operation of the unit.
