AKZ 231PRODUCT DESCRIPTION SHEET

DE AT BE

5019 310 53001

First-Last...

shelf positions

1.Control panel

2.Cooling fan* (not visible)

3.Top heating element (can be lowered)

4.Oven light

5.Round heating element (not visible)

6.Fan

7.Bottom heating element (not visible)

8.Oven dooor hinges

9.Oven cool door

*N.B.: The cooling fan switches on only when the oven or

cooktop has reached a certain temperature. The fan can run at

two speeds:

1.Full speed

2.Reduced speed

The fan speed depends on the temperature of the appliances.

After the oven and/or the cooktop switch off, the cooling fan

may, however, continue to run for a certain time to ensure

proper cooling.

ACCESSORIES

Push-push knobs

To use this type of knob, press it in the middle.

Turn the knob to the desired position.

Once cooking is over, turn the knob back to the position marked by 0 and press it again to restore

it to its initial setting.

COOKTOP FUNCTIONS TABLE

FOR A DESCRIPTION ON HOW TO USE THE OVEN, PLEASE REFER TO THE PROGRAMMER DESCRIPTION SHEET.

OVEN FUNCTIONS TABLE

Function

symbol

Function

Preset

temperature/level

Function description

(see details in the users manual)

0OVEN OFF

--

OVEN LIGHT

-To switch on the oven light.

MLTF

(Heat Maintenance)

35C

To keep a constant temperature, either 35°C

or 60°C.

STATIC

200CTo cook food at one shelf level. Preheating.

PASTRY

(Static+Fan)

175C

To cook on two shelf levels, at the same

temperature.

FAN

160C

To cook on more than one shelf level, at the

same temperature.

TURBOFAN

160C

To cook: large fruitcakes, stuffed vegetables,

timbales, poultry.

GRILL

3To grill small pieces of meat, toast, etc.

TURBOGRILL

(Grill+Fan)

3To grill large pieces of meat.

PROGRAMME

P1To bake pizza, bread, focaccia.

BOOSTER

200CFor fast preheating of the oven.

First

Last

Grid

Baking tray

Drip tray

Function

symbol

Function

Function description

(see details in the users manual)

KEEP WARMConstant temperature, 60°C.

DUAL ZONETo extend the heated area of the second part of oval or rectangular cooking zones.

ICPTo accelerate the heating of the selected cooking zone.

FAST BOILINGTo bring the water to the boil fast.

GENTLE HEAT Constant temperature, 35°C.

1-10POWER LEVELS-

STARTING THE OVEN

When the oven is connected to the power supply for the first time, or re-connected after a power

failure,

the display shows .

To start the oven:

turn

knob 1

to

0

.

press

button 2

.

The display shows --:--

.

32145678

1.Selector knob: to choose the oven functions.

2.Button to select and confirm the different operations (operate by single presses only).

3.Knob to set: time of day, cooking time, the time at which cooking should terminate,

the temperatures and the power levels (Function P).

4.Control knob for front, left cooking zone*01...10

5.Control knob for rear, left cooking zone*01...10

6.Control knob for rear, right cooking zone*01...10

7.Control knob for front, right cooking zone*01...10

8.Cooktop warning lights

*)

The cooktop control knobs are not interchangeable. After cleaning or servicing, they must be returned to their

original positions.
