AKZ 232PRODUCT DESCRIPTION SHEET

GB

5019 310 53721

First-Last...

shelf positions

1.Control panel

2.Cooling fan* (not visible)

3.Top heating element (can be lowered)

4.Oven light

5.Round heating element (not visible)

6.Fan

7.Bottom heating element (not visible)

8.Oven door hinges

9.Oven cool door

*N.B.:

The cooling fan switches on only when the oven or cooktop has

reached a certain temperature. The fan can run at two speeds:

1) Full speed

2) Reduced speed

The fan speed depends on the temperature of the appliances.

After the oven and/or the cooktop switch off, the cooling fan may, however,

continue to run for a certain time to ensure proper cooling.

ACCESSORIES

Push-push knobs

To use this type of knob, press it in the middle.

Turn the knob to the desired position.

Once cooking is over, turn the knob back to the position marked by 0 and press it again to restore it

to its initial setting.

COOKTOP FUNCTIONS TABLE

FOR A DESCRIPTION ON HOW TO USE THE OVEN, PLEASE REFER TO THE PROGRAMMER DESCRIPTION

SHEET.

OVEN FUNCTIONS TABLE

Function

symbol

Function

Preset

temperature/level

Function description

(see details in the user's manual)

0OVEN OFF-

-

OVEN LIGHT-

To switch on the oven light.

MLTF

(Heat Maintenance)

35C

To keep a constant temperature,

either 35°C or 60°C.

STATIC200C

To cook food at one shelf level. Preheating.

PASTRY

(Static+Fan)

175C

To cook on two shelf levels, at the same

temperature.

FAN160C

To cook on more than one shelf level,

at the same temperature.

TURBOFAN160C

To cook: large fruitcakes, stuffed vegetables,

timbales, poultry.

GRILL3

To grill small pieces of meat, toast, etc.

TURBOGRILL

(Grill+Fan)

3

To grill large pieces of meat.

PROGRAMMEP1

To bake pizza, bread, focaccia.

BOOSTER200C

For fast preheating of the oven.

Grid

Baking tray

Drip tray

Sliding shelves

Catalytic panels

Function symbolFunction

Function description

(see details in the users manual)

KEEP WARMConstant temperature, 60°C.

DUAL ZONE

To extend the heated area of the second part of oval or

rectangular cooking zones.

ICPTo accelerate the heating of the selected cooking zone.

FAST BOILINGTo bring the water to the boil fast.

GENTLE HEAT Constant temperature, 35°C.

1-10POWER LEVELS-

STARTING THE OVEN

When the oven is connected to the power supply for the first time, or re-connected after a power

failure,

the display shows .

To start the oven:

turn

knob 1

to

0

.

press

button 2

.

The display shows --:--

.

1

2

3

45

67

8

1.Selector knob: to choose the oven functions.

2.Button to select and confirm the different operations (operate by single presses only).

3.Knob to set: time of day, cooking time, the time at which cooking should terminate, the

temperatures and the power levels (Function

P

).

4.Control knob for front, left cooking zone*01...10

5.Control knob for rear, left cooking zone*01...10

6.Control knob for rear, right cooking zone*01...10

7.Control knob for front, right cooking zone*01...10

8.Cooktop warning lights

*)The cooktop control knobs are not interchangeable. After cleaning or servicing, they must be returned to their original positions.
