Sida 1/3
15
3
2
9
6
5
8
4
7
18 VDC
60 mA
1
1: INPUT (JACK) - Connect your bass here.
2: OUTPUT (JACK) - Connect a cord out to your amplier here.
3: 18 VDC 60 mA (JACK) - 2.1mm barrel jack, with the center negative for connecting an 18 Volt DC
regulated supply, 60 mA capacity or greater with a center negative plug. The Whirlwind PS18EFX
(included) is recommended for proper operation.
4: ATTACK SWITCH - Switches between three pre-dened attack rates. FAST causes the eect to kick in almost
instantaneously, MED allows some of the note’s initial attack to come through before the eect kicks in and SLOW
allows even more of the initial attack to come through.
5: OUTPUT LEVEL (KNOB) - Controls the over all volume of the pedal.
6: LIMIT/COMPRESS SWITCH - Switches between Compression and Limit mode. Compression gently evens out the
louder and softer levels in the signal and helps the bass “sit in the mix”. Think of limiting as a more aggressive form
of compression with a avor all its own. Experiment!
7: INPUT GAIN KNOB - Controls how much compression / limiting is applied to the signal. Adjusting this control
changes the overall volume of the eect. Use the OUTPUT LEVEL knob to match or even increase the overall volume
feeding your amp.
8: GAIN REDUCTION LEDs) - Displays the amount of limiting/compression in dBs.
9: ON/OFF (FOOTSWITCH) - Engages and disengages the eect. When engaged, the LED above the
footswitch will illuminate.
+
-
