NSF International requires the following water connection:
1. A quick disconnect or additional coiled tubing (at least 2x the depth of the unit) so that the machine
can be moved for cleaning underneath.
2. Thisequipmentistobeinstalledwithadequatebackowprotectiontocomplywithapplicable
federal, state and local codes..
3. Waterpipeconnectionsandxturesdirectlyconnectedtoapotablewatersupplyshallbesized,
installed and maintained in accordance with federal, state, and local codes.
1
Important Safeguards/Symbols
Service Manual, TCC
Thisapplianceisdesignedforcommercialuse.Anyservicingotherthancleaningandmaintenance
shouldbeperformedbyanauthorizedWilburCurtisservicecenter.
•DoNOTimmersetheunitinwateroranyotherliquid
•Nevercleanwithscouringpowders,bleachorharshchemicals.
Symbols:
WARNINGS – To help avoid personal injury Important Notes/Cautions
Sanitation Requirements
Curtis TCC Units are Factory Pre-Set and Ready to Go… Right out of the Box.
Generallytherewillneverbeareasontochangefactorysettings.However,shouldyouneedto
makeslightadjustmentstomeetyourteaneeds,adjustmentinstructionsareprovidedlaterinthis
manual.
SystemRequirements:
•WaterSource30–90PSI(MinimumFlowRateof1GPM).Ifincomingwatersupplyisgreater
than90PSI,additionalregulationisrequiredtomeettherange.
•Waterpipeconnectionsandxturesdirectlyconnectedtoapotablewatersupplyshallbe
sized,installedandmaintainedinaccordancewithfederal,state,andlocalcodes.
SETUP STEPS
Theunitshouldbelevel(lefttorightandfronttoback),locatedonasolidcountertop.Connecta
waterlinefromthewaterltertotheTCCserver.NOTE:Sometypeofwaterltrationdevicemust
beusedtomaintainatrouble-freeoperation.(Inareaswithextremelyhardwater,wesuggestthat
asedimentaryandtaste&odorlterbeinstalled.)Thiswillprolongthelifeofyoursystemand
enhanceteaquality.
INSTALLATION
1.Removedispenserfromcarton.
2.Runawaterlinetotheinletttingbehindthedispenser.Flushthenewwater-
line to remove foreign particles.
3.Connecta¼”aredexibleorcopperwaterlinetothemalettingontheback
of the dispenser.
4.Locatethewatersupplyvalvebehindtheunittoverifypositionisturnedon.
CAUTION:Werecommendedthatthewatersupplyvalve,behindunit,beturnedoffduring
non-business hours.
Wilbur Curtis Company, inC.
ModelsIncluded
•TCC1
•TCC2
•TCC3
NOTE:Watersource
pressure must be a
minimumof30PSI
pressure at all times
toinsurethequalityof
the of the product.
5.CleanouttheteaconcentratesystembeforeusingtheTCCserver.UseaBag-in-Box
stylecleaningsolutiontosimplifythecleaningprocedure.AcleanerlikeBevClean
beveragelinecleanercomesina3gallonbag-in-boxthatconnectsdirectlytoyour
bag-in-boxsystemforlinecleaning(http://bevclean.com).
a.Removethequickdisconnectfromtheteaconcentratebag.
b.PlacetheBIBcleanercontainernexttotheTCCteadispenser.Pullthespout
fromthecleanerboxthroughthemarkedarea.Removethecleartravelcapfrom
spout.Don’tworryaboutcleanerspillingwhenthecapisremoved.Thecaphas
an internal seal.
c. SnaptheQCDbagconnectorontothebagspout.
OFF
ON
ISO 9001:2008 REGIS-
TERED
WILBUR CURTIS CO., INC.
6913 West Acco Street
Montebello, CA 90640-5403
For the latest information go
to www.wilburcurtis.com
Tel: 800-421-6150
Fax: 323-837-2410
2
7. Carefullyliftthebagandsetthebagintothedispenser.
8. Resttubingontopofthebag.Routetubingtooppositeproductintake
holeonoorofdispenser(seeillustration,left).
9. Replacethetopcover.
10. Dispensebeveragefromfaucetuntildarkerproductstartstoappear(~5
seconds).
11. TheTCCserverisnowreadytodispensetea.
3. Pullofftheshipping
cap that covers the
spout on the bag.
4. PlacetheQCDnextto
the spout.
5. SlideQCDsideways,
over the bag spout.
QCDsnapsinplace.
6. PushQCDplungerinto
bag spout until plunger
topisushwithtopof
QCD.A“click”willbe
heardwhenitisfully
inserted.
LOAD PRODUCT
Bag-In-Box
1.PlaceateaconcentratebagonthecounternexttotheTCCdispenser.
2. RemovethetopcoverfromtheTCCdispenserandpulloutthehosewiththeQCD
bag connector.
d. Graspingthebagconnector(asshowninLoadProduct,step6),pushtheslidingprobeallthewayintothe
bagspout.A“click”willbeheardwhenitisfullyinserted.
e. Oncethecleaningsolutionboxisconnected,openthedispensingvalveonthedispenserandrunliquid
throughthevalveuntilthesanitizer(clearliquid)isdetected.Thedispensinglineisnowclean.
f. Disengagethebagconnectorbysnappingtheconnectorprobeoutandremovetheconnectorfromthespout.
g. ReattachtheteaconcentrateBIB.
h. Opendispensingvalveondispenseruntilteaowsfreely.
WATER PRESSURE AND MIXING VALVE
Thepressureregulatorshouldrarelybechanged.Primarytaste/brixadjust-
mentsshouldbedoneviathemixingvalvebyturningtherodandtastingthe
nishedproduct.98%ofavoradjustmentsshouldbedoneinthismanner.
The purpose of the regulator is to provide uniform water pressure so the venturi-
stylemixingdevicecanproduceastableanduniformblendofconcentrateand
waterandalsotoprotectthehydraulicsofthedispensingunitfrom“linepres-
sure”.Itisnottheprimaryadjustmentforthebrixlevel.Fromourtesting,ithas
beenshownthatexactPSIonthegagedoesnotdirectlycorrelatetoabrixlevel
from unit to unit and from installation location to installation location.
Secondarily,iftheprimaryadjustmentdoesn’tprovidetheidealbrixlevel,call
CurtisCareforinstructionsonhowtoadjusttheregulator.Asarule,verylittletasteadjust-
ment is achieved via the pressure regulator.
CAUTION: Do Not Exceed 25 psi (static). Equipmentfailureorleakagewill
result.
