2277 Harbor Bay Pkwy | Alameda, CA 94502 | 888.880.VENT | www.zephyronline.com
D E C 1 2. 0101
- Vertical Duct Application
- Foam Seal for Damper Closure
A B C D E
6”
7”
8”
6” 6” 2-7/8” 2-7/8” 1/4”
7” 7” 3-1/4” 3-1/4”1/2”
8” 8” 3- 5/8” 3-5/8” 3/4”
AK00029
AK00049
AK00069
M O D E L
D U C T
S I Z E
D I M E N S I O N S
BACK DRAFT DAMPE
FEATURES
3/4 View Side View
A
B
E DC
- Galvanized (G-90)
- NOT FOR USE WITH DRYER
VENT APPLICATIONS
Side View
C
B
A
A B C
7x6”
8x6”
8x7”
1-3/4” 1-3/4”5”
4-3/4”
4-1/4”
10x8” 5”
- Tapered for Best Air Flow
- Galvanized (G-90)
1-3/4” 1-3/4”
1-3/4” 1-3/4”
1-3/4” 1-3/4”
TAPERED REDUCER
FEATURES
AK00039
AK00037
AK00035
AK00040
M O D E L
D U C T
S I Z E
D I M E N S I O N S
R
round damper to prevent return-air from entering kitchen
Reduces round duct size
2277 Harbor Bay Pkwy | Alameda, CA 94502 | 888.880.VENT | www.zephyronline.com
D E C 1 2. 01 01
3/4 View Top View
Front View
A
C
D
G
E
B
F
- Aluminum Damper Included
- Mesh Bird Screen
- Rain Proof
AK00041
A B C D E
3-1/4”10” 5-5/8”11” 5”
F G
9-1/2”
12-3/4”
M O D E L
D I M E N S I O N S
FEATURES
3/4 View
Top View
Side View
A
D
E
B
C
C
F
H
G
I
- Low Profile
- Install of Any Roof Pitch
ABC D E
6”
7”
8”
12” 6” 3” 15” 10”
12” 7” 2-1/2” 15” 11”
15” 8” 3-1/2”15” 12”
10”
FG H I
15” 10” 2-1/2” 20” 16”
3-1/4”
5-1/8”
5-1/8”
5-1/2”
6-1/2”
3-1/4”
3-1/2”
4-1/4”
1-7/8”
1-7/8”
2”
2-1/4”
3-1/4”
3-1/4”
3-1/4”
3-1/2”
AK00046
AK00047
AK00048
AK00050
ROOF CAP EXHAUST, J-VENT
Exhaust cap for round ducting, installs on roof
M O D E L
D U C T
S I Z E
D I M E N S I O N S
FEATURES
- Mesh Bird Screen
- Galvanized (G-90)
- Galvanized (G-90)
- NOT FOR USE WITH INLET
VENT APPLICATIONS
WALL CAP EXHAUST, 3-1/4”x10” RECTANGULAR
Exhaust cap for rectangular ducting, prevents return-air, installs on exterior wall
2277 Harbor Bay Pkwy | Alameda, CA 94502 | 888.880.VENT | www.zephyronline.com
D E C 1 2. 01 01
3/4 View
E
F
HG
D
D
A B C
Top View Back View
- Mesh Bird Screen
- Rain Proof
ABCDE
6”
7”
6” 7-5/8”8” 1” 8-1/2”
7” 8-5/8”9-5/8”1” 8-1/2”
8” 10” 11-5/8” 1-3/4”8-1/2”
FG
8”
H
8-5/8”
9”
10-3/4”
10-3/8”
9-5/8”
11-1/8”
7-1/8”
8-1/8”
10-3/8”
AK00030
AK00031
AK00032
WALL CAP INLET, ROUND
Fresh air inlet for round ducting, commonly used with make-up air kits
M O D E L
D U C T
S I Z E
D I M E N S I O N S
FEATURES
ABCDE
6”
7”
6” 7-5/8”8” 1” 8-1/2”
7” 8-5/8”9-5/8”1” 8-1/2”
8” 10” 11-5/8” 1- 3/4”8-1/2”
10”
FG
8”
H
10” 12” 13” 1- 3/4” 8-1/2”
8-5/8”
9”
10-3/4”
10-3/8”
11-1/2”
9-5/8”
11-1/8”
13-5/8”
7-1/8”
8-1/8”
10-3/8”
13-7/8”
AK00042
AK00043
AK00044
AK00045
WALL CAP EXHAUST, ROUND
Exhaust cap for round ducting, prevents return-air, installs on exterior wall
D U C T
S I Z E
D I M E N S I O N S
M O D E L
3/4 View E
F
HG
D
D
A B C
Top View Back View
- Aluminum Damper Included
- Mesh Bird Screen
FEATURES
- Rain Proof
- Galvanized (G-90)
- Galvanized (G-90)
