FM3130
0719
Supersedes
New
INSTALLATION INSTRUCTIONS
MODEL 519 and 522 Condensate Pumps
NOTICE TO INSTALLER: Instructions must remain with installation.
P/N 155408
© Copyright 2019 Zoeller
®
Co. All rights reserved.
1. To help reduce the risk of electrical shock, a properly grounded
receptacle or control box of grounding type must be installed
and protected by a ground fault circuit interrupter (GFCI) in
accordance with the National Electrical Code and applicable
local codes. If pump is wired direct, a GFCI must be installed
in the control box. (SEE WARNING BELOW)
2. Make certain that the ground fault interrupter protected
receptacle or control box is within reach of the pump’s power
supply cord. DO NOT USE AN EXTENSION CORD. Extension
cords that are too long or too light do not deliver sufficient
voltage to the pump motor. But more important, they could
present a safety hazard if the insulation were to become
damaged or the connection end were to fall into a damp or
wet area.
3. Make sure the pump's electrical supply circuit is equipped with
fuses or circuit breakers of proper capacity.A separate branch
circuit, sized according to the National Electrical Code for
the current shown on the pump name plate is recommended.
1. Inspect all materials. Occasionally, products are damaged during shipment. If the unit is damaged, contact your dealer before using.
2.Carefullyreadalltheliteratureprovidedtofamiliarizeyourselfwithspecicdetailsregardinginstallationandusebeforeattemptingtheinstallation.
These materials should be retained for future reference.
1. Check to be sure your power source is adequate to handle
the amperage requirements of the motor as indicated on
the pump or unit I.D. tag.
2. All plumbing (discharge and drain lines) must be installed to
meet local codes.
3. This pump has been evaluated for use with water only.
4. TESTING FOR GROUND. As a safety measure, each electrical
outlet should be checked for ground using an Underwriters
Laboratory Listed circuit analyzer which will indicate if the
power, neutral and ground wires are correctly connected
to your outlet. If they are not, call a qualified licensed
electrician.
5. Installation and checking of electrical circuits and hardware
should only be performed by a qualified licensed electrician.
6.FOR YOUR PROTECTION ALWAYS DISCONNECT PUMP FROM
ITS POWER SOURCE BEFORE HANDLING.
7. Prop65 Warning for California residents: Cancer and
Reproductive Harm- www.P65Warnings.ca.gov.
CAUTION
SEE BELOW FOR
LIST OF CAUTIONS
REFER TO WARRANTY ON PAGE 2.
NOTE: Pumps with the “UL” mark and pumps with the “US” mark
aretestedtoULStandardUL778.CSACertiedpumpsarecertied
to CSA Standard C22.2 No. 108.
SEE BELOW FOR
LIST OF WARNINGS
Register your
Zoeller Pump Company
Product on our website:
http://reg.zoellerpumps.com/
Product information presented
here reects conditions at time
of publication. Consult factory
regarding discrepancies or
inconsistencies.
MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
TEL: (502) 778-2731 • 1 (800) 928-PUMP • FAX: (502) 774-3624
Visit our web site:
zoeller.com
