Sida 1/2
1. Check to be sure your power source is capable of handling the voltage
requirements of the motor, as indicated on the pump name plate.
2. These pumps are not designed or intended to be used to handle sewage
or efuent.
3. This pump has been evaluated for use with WATER only.
4. Maximum continuous operating water temperature for standard model
pumps must not exceed 104 °F (40 °C).
5. These pumps are not designed or intended to be used as a primary or
backup sump pump.
Note: Pumps with the "CSA" mark are tested to CSA Standard C22.2 No. 108.
REFER TO WARRANTY ON PAGE 2.
PERFORMANCE
Your pump is designed to effectively pump all clear storm and drain waters.
Although it will usually pass small particles suspended in water; grass, heavy
mud, sand or pea gravel can clog the pump and reduce pump performance.
This can usually be cleaned out by backushing with a garden hose through
the discharge. The normal performance that can be expected is as follows:
MODEL HP
GALLONS PER HOUR AT
DISCHARGE HEIGHT ABOVE
PUMPING LEVEL
SHUT-OFF
HEAD
5 ft 10 ft 15 ft
42 1/6 900 660 360 20 ft
44 1/4 1800 1320 720 20 ft
46 1/2 3300 2820 2160 34 ft
DO NOT USE FOR PUMPING OILS, GASOLINE OR ANY PETROLEUM BY-PRODUCTS.
Notice to Installer: Instructions must remain with installation.
1. Inspect your pump. Occasionally, products are damaged during shipment. If the unit is damaged, contact your dealer before
using. DO NOT remove the test plug in the cover.
2. Carefully read the literature provided to familiarize yourself with specic details regarding installation and use. These materials should be retained
for future reference.
1. Make sure there is a properly installed ground fault circuit interrupter (GFCI)
protected circuit available. All pumps are furnished with provisions for
proper grounding to help protect you against the possibility of electrical
shock.
2. Make certain that the ground fault receptacle is within the reach of the
pump’s power supply cord. DO NOT USE AN EXTENSION CORD. Extension
cords that are too long or too light do not deliver sufcient voltage to the
pump motor. But, more important, they could present a safety hazard if
the insulation were to become damaged or the connection ends were to
fall into water.
3. Make sure the pump electrical supply circuit is equipped with fuses
or circuit breakers of proper capacity. A separate branch circuit is
recommended, sized according the National Electrical Code for the current
shown on the pump name plate.
4. TESTING FOR GROUND. As a safety measure, each electrical outlet should
be checked for ground using an Underwriters Laboratory Listed circuit
analyzer which will indicate if the power, neutral and ground wires are
correctly connected to your outlet. If they are not, call a qualied licensed
electrician.
5. Installation and checking of electrical circuits and hardware should only
be performed by a qualied licensed electrician.
6. FOR YOUR PROTECTION, ALWAYS DISCONNECT PUMP FROM ITS POWER
SOURCE BEFORE HANDLING.
7. These pumps are supplied with a 3-prong grounded plug to help protect
you against the possibility of electrical shock. DO NOT UNDER ANY
CIRCUMSTANCES REMOVE THE GROUND PIN. The 3-prong plug must be
inserted in a mating 3-prong fault interrupter receptacle. If the installation
does not have such a receptacle, it must be changed to the proper type,
wired, and grounded in accordance with the National Electrical Code and
all applicable local codes and ordinances.
8. Risk of electric shock. This pump has not been tested for use in swimming
pool or marine areas.
9. Prop65 Warning for California residents: Cancer and Reproductive harm-
www.P65Warnings.ca.gov.
CAUTION
SEE BELOW FOR LIST OF
CAUTIONS
SEE BELOW FOR
LIST OF WARNINGS
INSTALLATION INSTRUCTIONS
MODEL: N42, LM44, N44, N46
PREINSTALLATION CHECKLIST - ALL INSTALLATIONS
FM2427
0219
Supersedes
1016
© Copyright 2019 Zoeller
®
Co. All rights reserved.
P/N 022508
Product information presented
here reects conditions at time
of publication. Consult factory
regarding discrepancies or
inconsistencies.
MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
TEL: (502) 778-2731 • 1 (800) 928-PUMP • FAX: (502) 774-3624
Visit our web site:
zoellerpumps.com
Register your
Zoeller Pump Company
Product on our website:
http://reg.zoellerpumps.com/
DATE INSTALLED:
MODEL NUMBER:
