Thank you for selecting the ZOOM RFX-300 (hereafter simply called the "RFX-300").
The RFX-300 is a sophisticated multi-effect processor with the following features and
functions.
Please take the time to read this manual carefully so as to get the most out of your RFX-
300 and to ensure optimum performance and reliability. Retain this manual, the warranty
card and all other documentation for future reference.
Safety Precautions/Usage Precautions
•••••••••••••••••••••••••• 2
Controls and Features
••••••••••••••••••••••••••••••••••••••••••••• 3
Top Panel
••••••••••••••••••••••••••••••••••••••••••••••••••••••• 3
Rear Panel
••••••••••••••••••••••••••••••••••••••••••••••••••••• 3
Getting Connected
•••••••••••••••••••••••••••••••••••••••••••••••• 4
To Operate the Unit on Batteries
••••••••••••••••••••••••••••••••• 5
Turning the Unit On
•••••••••••••••••••••••••••••••••••••••••••••••• 5
Adjusting the Sound of an Effect
••••••••••••••••••••••••••••••••• 6
Using the Bypass Function
••••••••••••••••••••••••••••••••••••••• 6
Effects and Parameters
••••••••••••••••••••••••••••••••••••••••••• 7
Troubleshooting
Specifications
• Ideal for use with a multi-track recorder
A total of 22 high-quality preset effects using a sampling frequency of 44.1 kHz and
18-bit A/D and D/A converters are built in. This includes reverb effects such as Hall,
Room, Plate, and Ambience, delay/modulation type effects as well as combination
effects, mixdown effects for changing the overall mood of a song. Any effect can be
called up quickly and without fuss. The unit is designed to be especially useful for
recording and mixdown on a multi- track recorder.
• Easy operation
The main parameters of preset effects can be adjusted directly with convenient knobs
on the top panel. This allows quick fine-tuning for optimum sound.
• Integrated tap input function
Tap input lets you set time-based parameters simply by tapping a key in the desired
interval. This makes it a snap to match delay time or modulation rate to the tempo of
a song.
• Versatile input/output configuration
The inputs and outputs of the RFX-300 accommodate both standard phone plugs and
RCA type phono plugs. Electronic instruments, multi-track recorders, various audio
components and a wide range of other equipment can be connected without hassle.
The phone jack input is equipped with a gain switch, allowing connection of
microphones as well. You can use the RFX-300 as a portable vocal effect device or as
a microphone preamp for recording.
• Dual power supply design
The dual power supply principle allows the unit to be powered from an AC adapter or
six IEC R6 (size AA) batteries. This is convenient for example when using the unit
on stage.
OPERATION MANUAL
Introduction
Contents
Safety Precautions
In this manual, symbols are used to highlight warnings and
cautions for you to read so that accidents can be prevented.
The meanings of these symbols are as follows:
Please observe the following safety tips and precautions to
ensure hazard-free use of the RFX-300.
• Power requirements
Since power consumption of this unit is fairly high, we
recommend the use of an AC adapter whenever
possible. When powering the unit from a battery, use
only an alkaline type.
[AC adapter operation]
• Be sure to use only an AC adapter which supplies 9
V DC, 300 mA and is equipped with a "center
minus" plug (Zoom AD-0006). The use of an
adapter other than the specified type may damage
the unit and pose a safety hazard.
• Connect the AC adapter only to an AC outlet that
supplies the rated voltage required by the adapter.
• When disconnecting the AC adapter from the AC
outlet, always grasp the adapter itself and do not pull
at the cable.
• When not using the unit for an extended period,
disconnect the AC adapter from the AC outlet.
[Battery Powered Operation ]
• Use six IEC R6 (size AA) 1.5V batteries (alkaline).
• The RFX-300 cannot be used for recharging.
Pay close attention to the labelling of the battery to
make sure you choose the correct type.
• When not using the unit for an extended period,
remove the batteries from the unit.
• If battery leakage has occurred, wipe the battery
compartment and the battery terminals carefully to
remove all remnants of battery fluid.
• While using the unit, the battery compartment cover
should be closed.
• Environment
Avoid using your RFX-300 in environments where it
will be exposed to:
• Extreme temperature
• High humidity or moisture
• Excessive dust or sand
• Excessive vibration or shock
• Handling
Since the RFX-300 is a precision electronic device,
avoid applying excessive force to the switches and
buttons. Also take care not to drop the unit, and do not
subject it to shock or excessive pressure.
• Alterations
Never open the case of the RFX-300 or attempt to
modify the product in any way since this can result in
damage to the unit.
• Connecting cables and input and output jacks
You should always turn off the power to the RFX-300
and all other equipment before connecting or
disconnecting any cables. Also make sure to disconnect
all cables and the AC adapter before moving the RFX-
300.
Usage Precautions
• Electrical interference
For safety considerations, the RFX-300 has been designed
to provide maximum protection against the emission of
electromagnetic radiation from inside the device, and
protection from external interference. However, equipment
that is very susceptible to interference or that emits
powerful electromagnetic waves should not be placed near
the RFX-300, as the possibility of interference cannot be
ruled out entirely.
With any type of digital control device, the RFX-300
included, electromagnetic interference can cause
malfunctioning and can corrupt or destroy data. Care
should be taken to minimize the risk of damage.
• Cleaning
Use a soft, dry cloth to clean the RFX-300. If necessary,
slightly moisten the cloth. Do not use abrasive cleanser,
wax, or solvents (such as paint thinner or cleaning
alcohol), since these may dull the finish or damage the
surface.
Please keep this manual in a convenient place for
future reference.
ZOOM RFX-300
2
Safety Precautions/Usage Precautions
Safety Precautions/Usage Precautions
Warning
Caution
Warning
Caution
This symbol indicates explanations
about extremely dangerous matters. If
users ignore this symbol and handle the
device the wrong way, serious injury or
death could result.
This symbol indicates explanations
about dangerous matters. If users ignore
this symbol and handle the device the
wrong way, bodily injury and damage to
the equipment could result.
Caution
Caution
Caution
