ZOOM CORPORATION 4-4-3 Kanda-surugadai, Chiyoda-ku, Tokyo 101-0062 Japan zoomcorp.com
© 2020 ZOOM CORPORATION Copying or reprinting this manual in part or in whole without permission is prohibited. Product names, registered trademarks and
company names in this document are the property of their respective companies. All trademarks and registered trademarks in this document are for identication
purposes only and are not intended to infringe on the copyrights of their respective owners.
Features
• Delivers a warm and rich broadcast sound
• Supercardioid polar pattern, high gain before feedback
• High SPL capability
• Hum-bucking coil to reduce interference
• The shock mount within the ZDM-1 also greatly reduces stage
noise and mechanical and environmental vibrations.
• The ZDM-1’s all-metal construction makes it very robust.
General Rules for Use
• For the best signal to noise ratio, the distance from the
microphone to the sound source should be as short as
possible.
• The sensitivity of a supercardioid microphone is highest on axis
and lowest at 120 to 135 degrees.
• To reduce crosstalk between microphones, a 1:3 guide line
should be followed: If the distance between microphone A to
the sound source A is “1”, then the distance between sound
source A and any other microphone should be more than 3
times.
Specications
Type: Dynamic | Polar Pattern: Supercardioid | Frequency Response:
50-18,000 Hz | Sensitivity: -54 dBV/Pa (2.0 mV) | Output Impedance: 200 Ω |
Min. Load Impedance: 200 Ω | Max. SPL: 135 dB | Connector: XLR-M
Furnished Accessories
Overall Dimension
Ø54 mm (Ø2.13")
150 mm (5.9")
Pivoting Stand
Mount
Threaded
adapter
0°
45°45°
90°90°
135°135°
180°
Polar Patterns
0
RELATIVE RESPONSE IN dB
FREQUENCY IN Hz
20000 Hz100005000200010005002001005020
-10
-20
dB
10
Frequency Response
Monitor
Loudspeaker (s)
Recommended
Loudspeaker Locations
P.A. System
Loudspeaker
120˚–135˚ 120˚–135˚
180˚
90˚ 90˚
0˚
ZDM-1
ZOOM DYNAMIC MIC
Windscreen
Z2I-4033-01
