ZOTAC ZBOX-MN320 Bruksanvisning

ZOTAC Skrivbord ZBOX-MN320

Läs gratis den bruksanvisning för ZOTAC ZBOX-MN320 (34 sidor) i kategorin Skrivbord. Guiden har ansetts hjälpsam av 22 personer och har ett genomsnittsbetyg på 4.9 stjärnor baserat på 11.5 recensioner. Har du en fråga om ZOTAC ZBOX-MN320 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/34

ZOTAC ZBOX

User’s Manual

No part of this manual, including the products and software described in it,

may be reproduced, transmitted, transcribed, stored in a retrieval system, or

translated into any language in any form or by any means,except documenta-

tion kept by the purchaser for backup purposes, without the express written

permission of ZOTAC.

Products and corporate names mentioned in this manual may not be reg-

istered trademarks or copyrights of their respective companies, and are

used for identication purposes only. All trademarks are the property of their

respective owners.

Every effort has been made to ensure that the contents of this manual are cor-

rect and up to date. However, the manufacturer makes no guarantee regard-

ing the accuracy of its contents, and reserves the right to make changes

without prior notice.

CAUTION:

Risk of explosion if the battery is replaced with an incorrect type. Batteries

should be recycled where possible. Disposal of used batteries must be in

accordance with local environmental regulations.

ZOTAC ZBOX

Table of Contents

Product Specications -------------------------------------------------------------------------- 3

Safety information -------------------------------------------------------------------------------- 4

Setting up your system ----------------------------------------------------------------------- 4

Care during use -------------------------------------------------------------------------------- 4

Welcome --------------------------------------------------------------------------------------------- 5

Package contents ------------------------------------------------------------------------------ 5

Getting to know your ZOTAC ZBOX -------------------------------------------------------- 6

Front view ---------------------------------------------------------------------------------------- 6

Rear view----------------------------------------------------------------------------------------- 7

Installing Hardware inside ZOTAC ZBOX ------------------------------------------------- 8

Installing a memory module ----------------------------------------------------------------- 8

Removing the memory module ------------------------------------------------------------- 9

Installing a hard disk -------------------------------------------------------------------------- 10

Setting up your ZOTAC ZBOX ---------------------------------------------------------------- 11

Positioning your ZOTAC ZBOX --------------------------------------------------------------- 13

Installing the stand ----------------------------------------------------------------------------- 13

Installing your ZOTAC ZBOX to a monitor ----------------------------------------------- 13

Installing drivers and software --------------------------------------------------------------- 14

Installing an operating system -------------------------------------------------------------- 14

Installing system drivers ---------------------------------------------------------------------- 14

Using your ZOTAC ZBOX ----------------------------------------------------------------------- 15

Conguring wireless connection ----------------------------------------------------------- 15

Conguring wired connection --------------------------------------------------------------- 15

Using a static IP ---------------------------------------------------------------------------- 15

Using a dynamic IP (PPPoE connection) -------------------------------------------- 16

Conguring audio output via an HDMI device ------------------------------------------ 16

Produktspecifikationer

Varumärke:	ZOTAC
Kategori:	Skrivbord
Modell:	ZBOX-MN320
Produkttyp:	Mini-PC, barebone
Bredd:	188 mm
Djup:	188 mm
Höjd:	44 mm
Förpackningens bredd:	240 mm
LED-indikatorer:	Ja
Processorfrekvens:	2.41 GHz
Processorfamilj:	Intel® Pentium®
Wi-Fi:	Ja
Bluetooth-version:	4.0
Antal HDMI-portar:	1
DVI-port:	Ja
Hörlursutgångar:	1
HDMI-version:	1.4a
Processor:	J2900
Intel® Wireless Display (Intel® WiDi):	Nej
Maximalt internminne:	8 GB
Intel® Hyper Threading Technology (Intel® HT Technology):	Nej
Intel® InTru™ 3D-teknik:	Nej
Intel® Insider™:	Nej
Intel® AES nya instruktioner (Intel® AES-NI):	Nej
Idle stater:	Ja
Intel® Small Business Advantage (Intel® SBA):	Nej
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Nej
Intel® Identity Protection Technology (Intel® IPT):	Nej
Intel® Stable Image Platform Program (SIPP):	Nej
S/PDIF-utgång:	Ja
Intel® FDI-teknik:	Nej
Intel® Rapid Storage Technology:	Nej
Intel® Virtualization Technology (Intel® VT):	VT-x
Antal lagringsenheter som stöds:	1
Typer av lagringsenheter som stöds:	HDD & SSD
Antal minnesplatser:	2
Typ av minneskort:	MMC, MS PRO, Memory Stick (MS), SD, SDHC, SDXC
Produktens färg:	Svart, silver
VESA-fäste:	Ja
Låddjup:	185 mm
processortillverkare:	Intel
Inbyggd processor:	Ja
Installerat operativsystem:	Nej
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	BGA 1170
Processorns kodnamn:	Bay Trail
Nätverksansluten (Ethernet):	Ja
AC-adapter inkluderad:	Ja
På / av-knapp:	Ja
Antal USB 2.0 anslutningar:	5
Minnesplatser, typ:	SO-DIMM
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	1
Processorkärnor:	4
Processorboostfrekvens:	2.66 GHz
Bluetooth:	Ja
Processortrådar:	4
Processorlitografi:	22 nm
Värmeavledningseffekt (TDP):	10 W
PCI Express-kortplatser version:	2.0
PCI Express konfigurationer:	1x4
Grafikadapterfamilj:	NVIDIA
Diskret grafikkortsmodell:	NVIDIA® GeForce® GT 730
Ombord grafikkort:	Ja
Uttag för mikrofon/linje in:	Ja
Intel® Stöldskydd Teknik (Intel® AT):	Nej
Intel® Turbo Boost Technology:	Nej
Förstärkt Intel Speedstep Technology:	Ja
Intel® Quick Sync Video Technology:	Ja
Execute Disable Bit-säkerhet:	Ja
CPU konfiguration (max):	1
Inbäddade alternativ:	Nej
Intel Virtualization Technology (VT-x):	Ja
Lagringsenhetens gränssnitt:	Serial ATA III
Storlekar som stöds på lagringsenhet:	2.5 "
Drivrutiner medföljer:	Ja
Chassityp:	Nettop
L2-cache:	2 MB
