Dual EnvVCA
4ms Company
User Manual 1.0 – October 31, 2022
The Dual EnvVCA is a dual analog envelope generator, slew limiter, and VCA. Each of the two
channels are identical and can be used separately or together.
Dual EnvVCA features:
•
Versatile linear envelope generator/LFO
•
Low-noise, low-distortion, DC-coupled exponential VCAs
•
100% analog
•
Sliders and Range switches control Rise and Fall times from ~1.25ms (800Hz) to > 2 min.
•
Time CV jack extends time range: ~125µs (8kHz) to ~10 min.
•
Independent attenuverters for Rise and Fall time
•
Blue/Red LEDs indicate strength and polarity
•Cycle buttons for looping envelopes (LFO)
•Trigger input jacks fire a one-shot envelope
•Cycle gate input jack toggles cycling for both channels
•EOR/F (End of Rise/Fall) gate outputs can be used to chain and sequence events
•Env Level and Offset knobs scale and shift Env Out without changing VCA volume
•Audio In and Out jacks for passing audio or CV through the VCA
•VCA CV inputs to use VCAs independently from the envelopes
•
VCA gain internally connected to envelope output when VCA CV jack is left unpatched
•Follow input jacks allow for slew limiting, sustain (ASR), and exotic filtering effects
•Re-trig jumpers allow for re-triggering during rise phase
RiseFall
RiseFallRiseFall
Level
RiseFall
Cycle
FollowFollow
Trigger
Time CV
RiseFall
Time CV
EOR
InIn
FallRise
Level
OffsetOffset
Slow
Fast
Slow
Fast
Audio B
OutOut
Audio A
AB
VCA CVVCA CV
Trigger
B
EOF
ENV
OUT
ORA
Env
Out
Slow
Fast
Med
Slow
Fast
Med
Dual EnvVCA
A
