Sida 1/2
Package Content
Quick Start Guide
HURRICANE MAG 120
ARGB PWM MAGNETIC FAN
Fan
x4
6-32# Screw
x12
M3 Screw
x12
Short Screw
x16
Fan-to Fan
Extension Cable
X1
Controller
with Power
Cable
x1
Overview
120mm
120mm
25mm
Magnetic Connector
(Male)
Magnetic Connector
(Female)
Controller with Power Cable
3-Pin ARGB
Connector
4-Pin PWM
Connector
Reset Header
Controller
7-Pin Connector (Female)
Fan-to-Fan Extension Cable
7-Pin Connector
(Male)
7-Pin Connector
(Female)
120 x 120 x 25mm
Rifle Bearing
Dimensions
Bearing Type
Addressable RGB LED
4-Pin PWM
5V 3-pin ARGB
Standard (Counterclockwise)
2000 RPM
54.82 ± 10% CFM
LED Profiles
Connector
Speed (RPM)
Maximum Air Flow
Maximum Static Pressure
Maximum Noise Level
2.74mm-H2O
23.36 dBA
DC 12V
DC 5V
Fan Rated Voltage
LED Rated Voltage
Operating Voltage
Fan Starting Voltage
Fan Rated Current
DC 7V~12V ± 5%
DC 7V
0.2A (Max)
0.86A (Max)
Auto-Restart
LED Rated Current
Fan Protection
Power Dissipation
Lighting Connector
Fan Direction Mode
MTTF
160,000 Hours / 40°C
1.56-2.4W
Reverse (Clockwise)
2000 RPM
49.27 ± 10% CFM
3.29mm-H2O
31.36 dBA
Quick Start Guide
HURRICANE MAG 120
ARGB PWM MAGNETIC FAN
Specification
Hg
Cd
Cr (Vl)
PBB
PBDE
限用物質及其化學符號
Restricted substance and its chemical symbols
Pb
Cable Connection
Magnetic fans
Connect the first fan in the chain to the fan controller. Align the fan's pin with the connector on the
controller, then firmly push the controller up to secure the connection.
Link the magnetic connectors of the fans together. Make sure the connectors are oriented correctly.
1.
2.
With an additional Fan-to-Fan extension cable, you can easily adjust your fan connection to suit any
scenarios you want.
3.
Connect the 3-Pin ARGB connector to the
motherboard's ARGB header.
Connect the 4-Pin PWM connector to the
motherboard.
Connect the case's Reset Switch to the fan's
Reset Header for easy controller switch
(after connection, you can click the reset
button to change fan direction).
1.
2.
3.
RESET SW
Controller
Connect the controller to your fans. Change the fan direction by pressing the switch. Wait a few seconds
for the LED indicator to change to the next color.
Switch LED Indicator Description
Blue Standard (Counterclockwise)
Red Stop
Green Reverse (Clockwise)
Quick Start Guide
HURRICANE MAG 120
ARGB PWM MAGNETIC FAN
Quick Start Guide
HURRICANE MAG 120
ARGB PWM MAGNETIC FAN
Learn More
Fan Installation
Interlocking Error Prevention Design
