User Instructions

Rev. 1/16

specications, diagrams, images, and instructions herein are

subject to change without notice. ADJ Products, LLC logo and

identifying product names and numbers herein are trademarks

of ADJ Products, LLC. Copyright protection claimed includes all

forms and matters of copyrightable materials and information

now allowed by statutory or judicial law or hereinafter granted.

Product names used in this document may be trademarks or

registered trademarks of their respective companies and are

hereby acknowledged. All non-ADJ Products, LLC brands and

product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis-

claim any and all liabilities for property, equipment, building, and

electrical damages, injuries to any persons, and direct or indi-

rect economic loss associated with the use or reliance of any

information contained within this document, and/or as a result

of the improper, unsafe, unsucient and negligent assembly,

installation, rigging, and operation of this product.

Europe Energy Saving Notice

Energy Saving Matters (EuP 2009/125/EC)

Saving electric energy is a key to help protecting the enviroment.

Please turn o all electrical products when they are not in use. To

avoid power consumption in idle mode, disconnect all electrical

equipment from power when not in use. Thank you!

Inno Color Beam Z19

ADJ Products, LLC - www.adj.com - Inno Color Beam Z19 User Manual Page 3ADJ Products, LLC - www.adj.com - Inno Color Beam Z19 User Manual Page 2

Inno Color Beam Z19 Warranty Registration

The Inno Color Beam Z19 carries a 2 year (730 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase

and warranty. You may also register your product online at www.

americandj.com. All returned service items whether under warranty or

not, must be freight pre-paid and accompany a return authorization

(R.A.) number. If the unit is under warranty you must provide a copy

of your proof of purchase invoice. Please contact ADJ customer sup-

port for a R.A. number.

Inno Color Beam Z19 Features

To optimize the performance of this product, please read these operat-

ing instructions carefully to familiarize yourself with the basic operations

of this unit. These instructions contain important safety information

regarding the use and maintenance of this unit. Please keep this manual

with the unit, for future reference.

Inno Color Beam Z19 General Instructions

Inno Color Beam Z19 Introduction

Unpacking: Thank you for purchasing the Inno Color Beam Z19 by

ADJ Products, LLC. Every Inno Color Beam Z19 has been thoroughly

tested and has been shipped in perfect operating condition. Carefully

check the shipping carton for damage that may have occurred during

shipping. If the carton appears to be damaged, carefully inspect your

xture for any damage and be sure all accessories necessary to oper-

ate the unit has arrived intact. In the case damage has been found

or parts are missing, please contact our toll free customer support

number for further instructions. Do not return this unit to your dealer

without rst contacting customer support.

Introduction: The Inno Color Beam Z19 is part of ADJ’s continuing

pursuit for creating high quality affordable intelligent fixtures. The Inno

Color Beam Z19 is a high performance, DMX intelligent, moving head

LED fixture. This fixture is a great piece for retail stores, displays, mood,

architectural, interior and exterior decoration, and clubs. This unit can

be used as a stand alone, or in a Master/Slave conguration. The unit

can also be controlled via DMX controller. This fixture is suitable for

theaters, studios, retail stores, and other similar locations.

Customer Support: ADJ Products, LLC provides a toll free cus-

tomer support line, to provide set up help and to answer any question

should you encounter problems during your set up or initial operation.

You may also visit us on the web at www.adj.com for any comments

or suggestions. Service Hours are Monday through Friday 8:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

ADJ Products, LLC.

PLEASE recycle the shipping carton when ever possible.

• RGBW Color Mixing

• 19 x 10W Quad Color LEDs

• Color Strobe Effect

• Color Mix Effect

• Pan/Tilt Inversion

• Electronic Dimming 0-100%

• Dimmer Curve Settings

• Built in Microphone

• DMX-512 protocol

• 14 DMX Channels

• 3 Operating Modes - Sound Active, Show Mode, & DMX Control

• Power Cord Daisy Chaining (See section below)

Inno Color Beam Z19 Power Cord Daisy Chaining

With this feature you can connect the xtures to one another

using the PowerCON input and output sockets. The quantity that

can be connected is 5 xtures maximum for 120V and 11 xtures

maximum for 240V. After the maximum xtures has been reached

you will need to use a new power outlet. They must be the same

xtures. DO NOT mix xtures.

Produktspecifikationer

Varumärke:	Adj
Kategori:	Effektmaskin
Modell:	Inno Color Beam Z19
Produkttyp:	Discostrålkastare
Inbyggd display:	Ja
Vikt:	9500 g
Bredd:	188 mm
Djup:	329 mm
Höjd:	395 mm
Sladdlängd:	1.5 m
Antal lampor:	19 lamp(or)
Lampans livslängd:	50000 h
Lämplig för inomhusbruk:	Ja
Spänning:	100 - 230 V
Ljuslägen:	DMX, Sound activated
Ljusstyrningsprotokoll:	DMX
Antal DMX-kanaler:	14 kanaler
Produktens färg:	Svart
Skärmtyp:	LED
Kontrolltyp:	Knappar
Ingångsfrekvens:	50 - 60 hz
Strömförbrukning (vanlig):	245 W
Lamptyp:	LED
XLR-ingång:	Ja
Strömkälla:	AC
Lampor:	10 W
Antal:	1
Kuldiameter:	- "
Dimbart område:	0 - 100 %
