User Instructions

Profile Panel RGB™ Introduction

©American DJ® - www.americandj.com - Prole Panel RGB™ User Manual Page 2

Rev. 12/10

Unpacking: Thank you for purchasing the Prole Panel RGB™ by

American DJ®. Every Prole Panel RGB™ has been thoroughly tested

and has been shipped in perfect operating condition. Carefully check

the shipping carton for damage that may have occurred during ship-

ping. If the carton appears to be damaged, carefully inspect your x-

ture for any damage and be sure all accessories necessary to operate

the unit has arrived intact. In the case damage has been found or parts

are missing, please contact our toll free customer support number for

further instructions. Do not return this unit to your dealer without rst

contacting customer support.

Introduction: The Profile Panel RGB™ is part of American DJ’s con-

tinuing pursuit for creating high quality affordable intelligent fixtures.

The Profile Panel RGB™ is a DMX intelligent LED stage panel/wash.

This wash can be used in a stand alone mode or connected in a Master/

Slave conguration. The unit can also be controlled via DMX controller.

This wash has four operating modes: Sound Active mode, Program

mode, RGB mode, and DMX control mode.

Customer Support: American DJ® provides a toll free customer sup-

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 9:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ®.

PLEASE recycle the shipping carton when ever possible.

ProfilePanel RGB

Profile Panel RGB™ Safety Precautions

©American DJ® - www.americandj.com - Prole Panel RGB™ User Manual Page 4©American DJ® - www.americandj.com - Prole Panel RGB™ User Manual Page 3

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken. Do not attempt to remove or break off the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out`

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to the point they exit from the unit.

• Cleaning -The fixture should be cleaned only as recommended by

t he manufacturer. See page 3 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (inclu-

d ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

Profile Panel RGB™ Warranty Registration

The Profile Panel RGB™ carries a 3 year (1095 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase

and warranty. You may also register your product online at www.

americandj.com. All returned service items whether under warranty or

not, must be freight pre-paid and accompany a return authorization

(R.A.) number. If the unit is under warranty you must provide a copy

of your proof of purchase invoice. Please contact American DJ® cus-

tomer support for a R.A. number.

Profile Panel RGB™ Features

To optimize the performance of this product, please read these operat-

ing instructions carefully to familiarize yourself with the basic operations

of this unit. These instructions contain important safety information

regarding the use and maintenance of this unit. Please keep this manual

with the unit, for future reference.

Profile Panel RGB™ General Instructions

• 288 Ultra Bright LEDs

• Mulit-Colors

• Color Strobe

• Electronic Dimming 0-100%

• Built in Microphone

• DMX-512 protocol

• 7 DMX Channel Modes: 2, 3, 4, 6, 7, 24, & 27 DMX Channels

Profile Panel RGB™ Cleaning

Due to fog residue, smoke, and dust cleaning the internal and exter-

nal optical lenses must be carried out periodically to optimize light

output.

1. Use normal glass cleaner and a soft cloth to wipe down the

outside casing.

2. Clean the external optics with glass cleaner and a soft cloth

every 20 days.

3. Always be sure to dry all parts completely before plugging

the unit back in.

Cleaning frequency depends on the environment in which the fixture

operates (i.e. smoke, fog residue, dust, dew).

Produktspecifikationer

Varumärke:	Adj
Kategori:	Effektmaskin
Modell:	Profile Panel RGB
Produkttyp:	Discostrålkastare
Inbyggd display:	Ja
Vikt:	2900 g
Bredd:	240 mm
Djup:	425 mm
Höjd:	51.5 mm
Antal lampor:	288 lamp(or)
Lampans livslängd:	100000 h
Lämplig för inomhusbruk:	Ja
Spänning:	100 - 240 V
Ljuslägen:	DMX, Sound activated
Ljusstyrningsprotokoll:	DMX
Produktens färg:	Svart
Skärmtyp:	LED
Kontrolltyp:	Knappar
ljus färg:	Blue, Green, Red
Ingångsfrekvens:	47 - 63 hz
Strömförbrukning (vanlig):	37 W
Lamptyp:	LED
XLR-ingång:	Ja
Strömkälla:	AC
Spridningsvinkel:	40 °
Antal:	1
Kuldiameter:	- "
Dimbart område:	0 - 100 %
