ASMB-561 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x ASMB-561 Startup Manual
• 1 x SATA power cables
• 1 x Standard I/O port bracket
• 1 x IO support plate
• 2 x M3 screws for M.2 storage
If any of these items are missing or damaged, please
contact your distributor or sales representative immediately.
Note: AcrobatReaderisrequiredtoviewanyPDFle.
Acrobat Reader can be downloaded at:
https://www.adobe.com/downloads.html
(Acrobat is a trademark of Adobe)
ASMB-561 Series LGA 4844 AMD EPYC™ 8004 micro ATX
Server Board with 6 x DDR5, 4 x PCIe5.0 x16, 5 x USB3.2
Gen1, Dual 10GbE, Dual 2.5GbE, TPM2.0 , IPMI
Startup Manual
Standard M/B Functions
• CPU: SP6 AMD EPYC™ 8004 8 to 64 cores processors
• BIOS: AMI 256 Mbit SPI BIOS
• System Memory: 6 x DDR5-4800 registered ECC DIMM,
Max. Capacity up to 596 GB
• SATA Interface: 8 via MCIO1&2 ports with SATA 6Gb/s
with MCIO to SATA cables
• M.2 Interface: 2x NVMe M.2 2280 supports PCIe5.0 x4
• Serial Ports: 1 at rear IO, supports RS-232
• Watchdog Timer: 255 level timer intervals
• USB Port: Supports up to 5 x USB 3.2 Gen1 ports (2 rear
ports, 2 ports from onboard 20-pin header and 1*Type-A
on board)
VGA Interface
• Chipset: ASPEED AST2600
• Display Memory: 64 MB
• Resolution: Supports VGA up to resolution 1920x1200
@ 60Hz refresh rate
Ethernet Interface
• Interface: 100/1000/2500 Mbps & 10 GbE Base-T
• Controller: LAN1/2: Intel I226; LAN3/4: Intel X710
Mechanical and Environment
• Dimensions (L x W): 244 x 244 mm (9.6” x 9.6”)
• Power Supply Voltage: +3.3 V, +5 V, ±12 V, +5 V
SB
• Power Consumption (mainboard only, excluding IO
device): •Max.load:+3.3V@0.88A,+5V@2.97A,
+12V @ 0.38 A,+5 VSB @ 0.04 A, +12V_8P @ 13.72 A
• Weight: 0.98 kg (weight of board)
• Operating Temperature: 0 ~ 60°C (depending on CPU)
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com
Register your products on our website and get 2
months extra warranty for Free at:
http://www.register.advantech.com
This manual is for the ASMB-561 series Rev. A1.
Part No. 2042B56100
Printed in China
1st Edition
August 2025
