ASMB-585 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

•1 ASMB-585 Startup Manual

•1 Driver CD (user’s manual is included)

•2 Serial ATA HDD data cables

•2 Serial ATA HDD power cables

•1 I/O port bracket

•1 Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF

file.Acrobat Reader can be downloaded at:

http://www.adobe.com/downloads/ (Acrobat is a

trademark of Adobe)

ASMB-585 Intel LGA1151 Xeon E3-1200 v5 /Core i3/i5/i7

series Micro ATX Server Board with 4 x PCIe slots, 6 x

USB3.0, 4 x GbE ports

Startup Manual

Standard SBC Functions

•CPU: Intel LGA1151 Xeon E3-1200 v5 /Core i3/i5/i7

series processors

•BIOS: AMI 128 Mb SPI BIOS

•Chipset: Intel®

C236

•System memory: Dual Channel DDR4 ECC/Non-ECC

1600/1866/2133 MHz unbuffered DIMM, Max. 64 GB

Note: Due to the inherent limitations of PC architecture,

the system may not fully detect 32 GB RAM

when 64 GB RAM is installed.

•SATA3 Interface: 7 SATA3 6Gb/s ports to support Intel

Matrix Storage with software RAID 0, 1, 10 & 5. (for

Windows only)

•Serial ports: Six serial ports, only supports RS-232

•Keyboard/Mouse connector: Supports standard PS/2

keyboard and mouse via KMBS1 pin header

•Watchdog timer: 255 level timer intervals (sec)

•USB 3.0: Supports up to Six USB 3.0 ports. Four ports

are in rear I/O, and two ports are on-board pin header.

•USB 2.0: Supports up to seven USB 2.0 ports (1* Type-A)

Display Interface

•Chipset: CPU integrated Intel HD graphics controller

•Display Memory: 1 GB maximum shared memory with 2

GB and above system memory installed

•Resolution:

- Supports RGB up to 1920 x 1200 resolution @ 60 Hz

refresh rate

- Supports DVI up to 1920 x 1200 resolution@ 60 Hz

refresh rate

Ethernet Interface

•Interface: 10/100/1000 Mbps

•Controller: LAN1:Intel

®

I219LM; LAN2 ~ LAN4: Intel®

I201AT

Mechanical and Environmental

•Dimensions (L x W): 244 x 244 mm (9.6” x 9.6”)

•Power supply voltage: +3.3 V, +5 V, ±12 V, 5 Vsb

•Power consumption: Max. load: +3.3 V @ 17.57 A, +5

V @ 20.5 A, +12 V @ 16.74 A, +12 V (8P) @ 23.27 A, +5

Vsb @ 2 A, -12 V @ 0.3 A

•Operating temperature: 0 ~ 60° C (Depends on CPU

speed and cooler solution)

•Weight: 0.5 kg (weight of board)

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/applied-computing-

systems/

For technical support and service, please visit our

support website at:

http://support.advantech.com.tw/support/new_de-

fault.aspx

This manual is for the ASMB-585 series Rev. A1

Part No. 2001058511

Print in China

2nd Edition,

November 2015
