ASMB-786 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

•1 Startup manual

•2 Serial ATA HDD data cables

•2 Serial ATA HDD power cables

•1 COM cable

•1 I/O port bracket

•1 Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF

le.AcrobatReadercanbedownloadedat:

http://www.adobe.com/downloads/ (Acrobat is a

trademark of Adobe)

ASMB-786 LGA 1151 Intel® Xeon® E and 8th/9th Gen

Core™ATX Server Board with 4 x DDR4, 7 x PCIe,

6 x USB 3.1, 8 x SATA3, Quad/Dual LANs, IPMI

Startup Manual

Standard Functions

•CPU: Intel LGA1151 Xeon E-21xx/22xx and 8th/9th Gen

Core i3/i5/i7 series processors

•BIOS: AMI 256 Mb SPI BIOS

•Chipset: Intel C246

•System Memory: Dual Channel DDR4 ECC/Non-ECC

2666/2400/2133MHzunbu󰀨eredDIMM,Max.128GB

Note: Due to the inherent limitations of PC architecture,

the system may not fully detect 128 GB RAM

when 128 GB RAM is installed.

•SATA3 Interface: 8 SATA3 6Gb/s ports to support Intel

Rapid Storage Technology Enterprise with software RAID

0, 1, 10 & 5. (for Windows only)

•Serial Ports: Two serial ports onboard, only support RS-

232 (one can be in rear IO via COM cable connection)

•Keyboard/Mouse Connector: Supports standard PS/2

keyboard and mouse via KMBS1 pin header

•Watchdog Timer: 255 level timer intervals (sec/min)

•USB 3.1: Supports up to six USB 3.1 ports, four Gen2

ports in rear I/O and two Gen1 ports from on-board pin

header

•USB 2.0: Supports up to seven USB 2.0 ports (1* Type-A)

Display Interface

•Chipset: CPU integrated Intel HD graphics controller

•Display Memory: 1 GB maximum shared memory with

2 GB and above system memory installed (BIOS default

is 256 MB)

•Resolution:

- Supports VGA up to 1920 x 1200 resolution @ 60 Hz

refresh rate

- Supports DVI up to 1920 x 1200 resolution@ 60 Hz

refresh rate

- Supports HDMI 2.0 up to 2K/4K resolution @ 60Hz

Ethernet Interface

•Interface: 10/100/1000 Mbps

•Controller: LAN1:Intel

®

I219LM; LAN2 ~ LAN4: Intel®

I210AT (LAN2 is BMC shared NIC; LAN3/4 is for G4 SKU

only)

Mechanical and Environmental

•Dimensions (L x W): 244 x 304 mm (9.6” x 12”)

•Power Supply Voltage: +3.3 V, +5 V, ±12 V, 5 Vsb

•Power Consumption: Max. load: +3.3 V @ 3.44 A, +5 V

@ 2.61 A, +12 V @ 1.04 A, +12 V (8P) @ 6.3 A, +5 Vsb

@ 0.09 A

•Operating Temperature: 0 ~ 60° C (depends on CPU

speed and cooler solution)

Specications

Packing List

For more information on this and other Advantech prod-

ucts, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our sup-

port website for ASMB-786 at:

https://advt.ch/searca78a8

Register your products on our website and get 2 months

extra warranty for FREE at:

http://www.register.advantech.com

This manual is for the ASMB-786 series Rev. A1..

Part No. 2001S78611

Printed in China

2nd Edition

January 2020
