AIMB-785 Startup Manual 1
AIMB-785 LGA1151 Intel® Core™ i7/i5/i3 ATX with
Triple Display, DDR4, SATA III
Startup Manual
Specications (Cont.)
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the AIMB-785 series Rev. A1.
Part No. 2001078513
Printed in China
4th Edition
October 2024
• SATA interface: Four on-board Serial ATA 3.0 connectors
support data transmission rates of up to 600 MB/s. All
four SATA 3.0 ports support Advanced Host Controller
Interface (AHCI) technology.
• PCIe and PCI slots: 1 PCIe x16 expansion slot, 3 PCIe
x4 expansion slots, 3 PCI slots 32-bit/33 MHz PCI 2.2
compliant
• LPC interface: Advantech-designed LPC connector sup-
ports dTPM 2.0 module
• Serial ports: Six serial ports: COM1, COM2 and COM4 ~
6 are RS-232; COM3 is RS-232/422/485 with BIOS menu
options
• Keyboard/mouse connector: An external keyboard and
mouse connector on the motherboard is supported. No
PS/2 keyboard/mouse connector is supported in the rear
I/O.
• Watchdog timer: 255 sec timer intervals
• USB 3.0/2.0: Thirteen USB ports: 1/2/3/4/13/14 are USB
3.0; others are USB 2.0.
Graphics Interface
• Chipset: CPU integrated graphics controller
• Display Memory: 1 GB maximum shared memory with 2
GB and above system memory installed
• Resolution: Supports DVI up to 1920 x 1200 resolution
@ 60 Hz refresh rate.
Supports VGA up to 1920 x 1200 resolution @ 60 Hz
refresh rate.
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1: Intel
®
I219LM; LAN2: Intel
®
I210AT
Mechanical and Environmental
• Dimensions (L x W): 304.8 x 244 mm (12” x 9.6”)
• Power supply voltage: +3.3 V, +5 V, +12 V, +5 Vsb
• Power consumption:
Intel® Core™ Intel® I7-6700 3.4 GHz; DDR4 8 G x 4
Maximum: +3.3 V at 1.02 A, +5 V at 1.96 A, +12 V at 1.14
A, +5 Vsb at 0.08 A, -5 V at 0.03 A, -12 V at 0.06 A
• Operating temperature: 0 ~ 60°C (depending on CPU)
• Weight: 0.7 kg (weight of board)
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 AIMB-785 motherboard
• 1 AIMB-785 Startup Manual
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 1 I/O port bracket
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
le.AcrobatReadercanbedownloadedat:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
Specications
Standard Functions
• CPU: LGA1151 6th and 7th Gen Intel® Core™ i7/i5/i3
and Celeron®/Pentium® processors
Note: Only 6th Gen Intel® processors can support
Windows 7.
• BIOS: AMI 128 Mb SPI BIOS
• Chipset: Intel® Q170 chipset
• System memory: Up to 64 GB with four 288-pin DIMM
sockets, supporting dual-channel DDR4 1866/2133
SDRAM.AIMB-785supportsnon-ECCunbueredDIMMs
anddoesnotsupportanymemorycongurationthat
mixesnon-ECCwithECCunbueredDIMMs.
Note: Due to the inherent limitations of PC architecture,
the system may not fully detect 64 GB RAM
when 64 GB RAM is installed.
