PCE-5B05-04 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
PCE-5B05-04A1E
startup manual 1st. ED p/n: 200K5B0520
M4*6*0.7 round screws
(15 pcs.) p/n: 1939000410
2 years quality warranty
card p/n: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
1.
2.
3.
PCE-5B05-04A1E Backplane: 5-slot BP for 5-slot Chassis, 1 PICMIG
1.3, 4 32-bit PCI
Startup Manual
Standard Functions
PICMIG 1.3 slots: PCE-5B05-04 backplane supports
PCE-5xxx CPU boards
32-bit PCI: Four 32-bit / 33 Mhz PCI slot
USB (2.0) support: Two USB 2.0 port pin headers (sup-
ports up to 4 USB port)
Mechanical and Environmental
Dimensions: 106.5 x 327.66 mm
Power supply type: +12 V, +5 V, -12 V, -5 V, +3.3 V, +5
VSB
Power requirements: Refer to the CPU Board , add-on
card & peripherals
Operating temperature: 0 ~ 60° C
Weight: 0.3 kg
•
•
•
•
•
•
•
•
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw
This manual is for the PCE-5B05-04 Series Rev. A1
Part No. 200K5B0520
Printed in China
1st Edition
Dec. 2010
