PCE-5B06-00A1E Startup Manual 1
PCE-5B06-00A1E Backplane: 6-slot BP for 6 slot Chassis, 1 PICMIG 1.3, 4 PCIe
PCE-5B06-00A1E Backplane: 6-slot BP for 6 slot
Chassis, 1 PICMIG 1.3, 4 PCIe
Startup Manual
Before you begin installing your card, please make sure
that the following materials have been shipped:
If any PCE-5B06-00A1E of these items are missing or
damaged, contact your distributor or sales representative
immediately.
Standard Functions
• PICMIG 1.3 slots:
PCE-5B06-00 supports PCE-5xxx CPU boards
• PCIe slots:
PCE-5B06-00 supports one PCIe x 16 slot, four PCIe x 1
slot
• USB (2.0) support: Four USB 2.0 port pin headers
Mechanical and Environment
• Dimensions: 317.5 x 142.17 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V
+5VSBY, +3.3VSBY
• Power requirements: Refer to the CPU Board, add-on
Card & Peripherals
• Operating temperature: 0 ~ 60° C
• Weight: 0.3 kg (weight of board)
Packing list Specifications
• 2 Two Port USB Cable p/n: 1700002204
• PCE-5B06-00A1E User Manual
1st.ED
p/n: 200K5B0610
• M4*6*0.7 Round Screws (15 pcs)
p/n: 1939000410
• 2 years quality warranty card p/n: 2190000902
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-5B06-00A1E series Rev. A1
Part No. 200K5B0610
Printed in China
1st Edition
Feb. 2007
2 PCE-5B06-00A1E Startup Manual
The backplane has a number of connectors and jumpers that
allow you to configure your system to suit your application. The
table below lists the function of each of the jumpers and con-
nectors:
Connectors and Jumpers
Connectors
Label Function
SHBA1~SHBD1 PICMG1.3 CPU board slot
PPCIE3 PCIe x 16 slot
PPCIE1,PPCIE2,
PPCIE4,PPCIE5
PCIe x 1 slot
EATXPWR1 ATX2.0 24-pin Power Connector
ATX12V1 ATX 12V 4-pin Power Connector
EATX12V1 ATX 12V Auxiliary 8-pin Power Connector
PWR3V1 3.3V Auxiliary 8-pin power connector
VOLT1 Alarm board / CMM Power Connector
FAN1 FAN Connector
FAN2 FAN Connector
FAN3 FAN Connector
FAN4 FAN Connector
FANDEC1 FAN speed detector Connector
SMBUS1 SMBus Connector for chassis monitor
SMBUS2 SMBus Connector for chassis monitor
KBMS1 External Keyboard/Mouse Connector
KBMS2 External Keyboard/Mouse Connector
JFP1 Power and Reset button Connector
IPMB1 IPMB Connector
USB12 Two USB port pin header
USB34 Two USB port pin header
Jumpers
Label Function
PSON1 ATX / AT Mode Selection
EATXPWER1
Pin Name
1 3.3 V
2 3.3 V
3 GND
4 5 V
5 GND
6 5 V
7 GND
8 Power OK
9 5 V SBY
10 12 V
11 12 V
12 3.3 V
13 3.3 V
14 -12 V
15 GND
16 PSON#
17 GND
18 GND
19 GND
20 -5 V
21 -5 V
22 5 V
23 5 V
24 GND
ATX12V1
Pin Name
1 GND
2 GND
3 12 V
4 12 V
EATX12V1
Pin Name
1 GND
2 GND
3 GND
4 GND
5 12 V
6 12 V
7 12 V
8 12 V
PWR3V1
Pin Name
1 3.3V
2 3.3V
3 3.3V
4 GND
5 GND
6 GND
VOLT1
Pin Name
1 5VSBY
2 GND
3 GND
4 -5V
5 5V
6 3.3V
7 -12V
8 12V
FAN1 - FAN4
Pin Name
1 GND
2 12V
3 FANIO1~FANIO4
FANDEC1
Pin Name
1 FANIO1
2 FANIO2
3 FANIO3
4 FANIO4
5 N/A
6 N/A
7 N/A
SMBUS1 ~ SMBUS2
Pin Name
1 5V
2 C-SMBBUS
3 C-SMBDAT
4 GND
PCE-5B06-00A1E Startup Manual 3
KBMS1 ~ KBMS2
Pin Name
1 KBCLK
2 KBDAT
3 MSDAT
4 GND
5 5V
6 MS_CLK
IPMB1
Pin Name
1 IPMB_CLK
2 IPMB_DAT
3 GND
USB12
Pin Name
1 USBV0
2 USBV0
3 USBD0-
4 USBD1-
5 USBD0+
6 USBD1+
7 GND
8 GND
9 Null
10 GND
USB34
Pin Name
1 USBV2
2 USBV2
3 USBD2-
4 USBD3-
5 USBD2+
6 USBD3+
7 GND
8 GND
9 Null
10 GND
JFP1
Pin Name
1 PWRBTN
2 PWRBTN
3 RESET
4 RESET
PSON1: ATX/AT Mode Selection
Jumper Setting Function
1-2 AT mode
2-3* ATX mode
*: Default
1 2 3 2 31
