SQFlash

SATA Slim 630

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.0 Page 1 of 24 Apr. 1, 2016

SATA Slim 630

Datasheet

(SQF-SLMxx-xG-S9x)

SQFlash

SATA Slim 630

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.0 Page 2 of 24 Apr. 1, 2016

CONTENTS

1. Overview ............................................................................................ 4

2. Features ............................................................................................. 5

3. Specification Table ............................................................................ 6

4. General Description .......................................................................... 8

5. Pin Assignment and Description ................................................... 10

5.1

SATA Slim disk module Interface Pin Assignments (Signal Segment) ........................... 10

5.2

SATA Slim disk module Interface Pin Assignments (Power Segment) .......................... 10

6. Identify Device Data ........................................................................ 11

7. ATA Command Set .......................................................................... 15

8. System Power Consumption ......................................................... 21

8.1

Supply Voltage .............................................................................................................. 21

8.2

Power Consumption ...................................................................................................... 21

9. Physical Dimension ........................................................................ 22

Appendix: Part Number Table ........................................................... 23

Produktspecifikationer

Varumärke:	Advantech
Kategori:	ej kategoriserat
Modell:	SQF-SLM 630
Bredd:	39 mm
Djup:	4.5 mm
Höjd:	54 mm
Gränssnitt:	Serial ATA III
Minnestyp:	SLC
Komponent för:	PC
Dataöverföringshastighet:	6 Gbit/s
Skyddsfunktioner:	Shock resistant, Vibration proof
Temperatur vid drift:	0 - 70 ° C
Solid-state drive kapacitet:	32 GB
SSD-diskens formfaktor:	1.8"
