VEGA-330 Startup Manual 1

Before you start installing your card, please make sure that

the following items have been shipped:

1 x VEGA-330 card

1 x 1960092232T000 heatsink with thermal pad

1 x Edge AI Suite download card

2 x 1930006235-01 screws (color: Black)

2 x 193B0204C0 screws (color: Silver)

1 x Startup manual

1 x China RoHS

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Product Pictures

Top View Bottom View

VEGA-330 Intel

TM

Movidius

TM

Myriad X Edge AI Module

Startup Manual

1. Remove the thermal pad protecting lm.

2. Check the installation direction as below, the top side of

the VEGA-330 has components which generate heat,

and should contact directly with the thermal pad.

3. Align the two diagonal screw holes of the VEGA-330

to the screw holes of heatsink, and tap VEGA-330 top

side and heatsink together.

Heatsink Installation

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://support.advantech.com

This manual is for the VEGA-330.

Part No. 2046033000

Printed in China

1st Edition

July 2019
