Outdoor Luminaires Part # BWSW2400L41RB :
Wall Mount
120VAC / 60Hz
Page 1 of 1 8061183 R1
Limited Factory Warranty
This product is manufactured by AFX Inc. AFX warrants this xture is free from defects in materials and workmanship when installed and used under normal operating conditions for a period of 5 years from
date of purchase. This warranty covers all component parts and extends only to replacement of defective xture or components; it does not cover failure due to improper installation, misuse, mishandling or
damage incurred in transit. For questions, please call AFX at 1- -873-2326. 800
Safety Precautions
Read all safety precautions and installation instructions carefully before installing or servicing this xture. Failure to comply with these instructions could result in potentially
fatal electric shock and/or property damage.
It is recommended that a qualied electrician perform all wiring. This xture must be wired in accordance with all national and local electrical codes.
Do not handle any energized xture or attempt to energize any xture with wet hands or while standing on a wet or damp surface or in water.
This xture is designed for use in a 120VAC, 60Hz fused circuit. Not compatible with dimmers.
To reduce the risk of electrical shock, and to assure proper operation, this xture must be adequately grounded. To accomplish proper grounding, there must be a separate
ground wire (green) contact between this xture and the ground connection of your main power supply panel.
This xture is intended to be used for general door lighting in wet locations, mounted at least 48 inches above the ground level.out
Disclaimer
Changes or modications not expressly approved by the party responsible for compliance could void NOTE: This equipment the user’s authority to operate the equipment.
has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and Canadian ICES-005 (B) / NMB-005 (B). These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiver antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult with the dealer or an experienced radio/TV technician for help.
Any modications to this xture may void the warranty and interfere with the safe operation of the luminaire.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
ASSEMBLY INSTRUCTIONS
Step 1 - Preparing for installation.
A. at fuse or circuit breaker box before installing or Disconnect electrical power
servicing any part of this xture.
B. Carefully remove the xture from the carton.
C. Remove mounting bracket from the xture. (1)
D. Install mounting bracket ) to junction box (not provided) by securing it with (1
two screws (2 Install stem (3) to mounting bracket allowing only about 1-1/8). ”
exposed. Then secure with jam nut (5) with lock washer (4).
Wiring-all wiring must take place inside junction box (not included).
Caution: Make sure power is o at fuse or circuit breaker box. Check power wires
for damage or scrapes. Use wire suitable for at least °C (194°F). 90
Note: Most dwellings built before 1985 have supply wire rated to 60C. Consult a
qualied electrician before installing.
Step 2 Wiring xture. –
A. Make all wire connections to appropriate wire. Secure with wire nuts
(provided) .
B. Connect the green wire from the xture to the supply power source ground
wire.
C. The black wire from the xture is connected to the black ) wire from supply (L
power source.
D. The white wire from the xture is connected to the white (N) wire from supply
power source.
E. Tuck all connections neatly into the junction box.
Step 3 Mounting. –
A. Install xture (6) over the mounting bracket (1 by aligning center hole to the )
stem (3) and secure with nial (7 ).
B. Install diuser (8) by engaging top edge with the xture housing, and align
bottom holes then secure with two screws (9 ).
C. Apply a small bead of silicone (not included) s instruction per manufacturer’
around the perimeter of the xture (6) where it contacts with the surface of wall.
D. Note: Photocell sensor will automatically turn lights o during daytime. Plastic
cap (included) with xture to cover PC sensor for override operation or testing.
Step 4 - Restore power at fuse or circuit breaker box .
