AR2412 Getting Started Guide 1 iss.3 AP9991
Copyright Allen & Heath Ltd, Kernick Industrial Estate, Penryn, TR10 9LU, UK. All rights reserved. © 2021
AR2412
Getting Started Guide
The is a rack mountable remote audio unit for all Allen & Heath digital mixing systems AR2412 19”
compatible with the dSnake protocol It provid remote controlled mic/line preamps and XLR line . es 24 12
outputs.
Using a single network cable the can be connected directly t t mixer the expansion port then , AR2412 o he ,
allows a cascaded (daisy-chain connection to an . ) AB168 or AR84
A personal monitoring system can also be connected to the dedicated port provided or a ME Monitor
cascade . d AB168
.A maximum of two dSnake remote units can be connected to each mixer dSnake port’s
The used to increase the number of I/O sockets in a system position both sockets and AR2412 is and
AD/DA conversion close to the source/stage. It will not increase the number of processing channels
available the system and must be connected to a mixer where the audio can be processed and routed. in
Compatibility and Cable
The uses the 48kHz dSnake protocol, which is a layer 2 fast ethernet protocol designed for AR2412 ,
point- -point connection This means it can connected the dedicated dSnake ports included oto s. be to n
the and systems or used with the intelligent SLink port which can switch to a dSnake mode. GLD Qu
Refer to the latest documentation for your mixer available from for more informa www.allen-heath.com tion
on connecting patching, and controlling the with your system. , AR2412
Cat5e (or higher) STP ( hielded wisted air) cable should be used, with a maximum cable ngth of S T P le
100m (330ft between each unit. Use of passiv couplers to join cables will reduce this distance. ) e
High-quality touring grade cables are available through your A&H dealer. Please see www.allen-
heath.com/ahproducts/cat5/ for more details.
AR-84
AR-2412
MIXER
AB-168
AR-2412
MIXER
AR-2412
MIXER
AR2412 Getting Started Guide 2 iss.3 AP9991
Copyright Allen & Heath Ltd, Kernick Industrial Estate, Penryn, TR10 9LU, UK. All rights reserved. © 2021
Connection, Automatic firmware matching and LED behaviour
When powered, the Power LED near to the mains power connection will illuminate. ‘On’
On connecti to a mixer the on , AR2412 will automatica y chec and match its firmware to the mixer model ll k
and mixer firmware versi . on
If a update to firmware is required, it will happen automatically. This may take up to 2 minutes to n
complete. During an update, the port will flash red and once the update is complete, the ‘Lnk/Err’ LED
AR2412 will automatically reboot.
When running the correct firmware and connected to a mixer /Err next to the dSnake port , the ‘Lnk ’ LED
will flash yellow to show link activity and t on the front panel will ill inate. he ‘Ready’ LED um
AR2412 Front Panel Layout
Input sockets AR241224 balanced XLR mic/line inputs. The preamps are built into the and
their Gain, Pad and 48V phantom power are controlled remotely from the mixer via the dSNAKE link.
Refer to mixer documentation fo formation on patching these sockets to input channels other r in or
destinations in the system.
Output sockets 12 balanced XLR outputs operating at nominal +4dBu line level. Refer to mixer
documentation for information on patching output signals to these sockets.
dSNAKE port EtherCon/RJ45 socket to connect directly to the mixer This carries inputs, .
outputs and /monitor sends to and from the as well as preamp control and system status ME AR2412
messages.
EtherCon/RJ45 socket to connect a /monitor system. EXPANDER port ME
EtherCon/RJ45 socket to connect an , a a /monitor EXPANDER port AB168 n AR84 or ME
system.
EtherCon locking connectors are recommended to prevent damage to cables or ports and
avoid accidental disconnection.
Read the Safety Instructions Sheet included with the product and e information printed on the panel before operating. th
A limited -year es to this product, the conditions of which can be found at: one manufacturer’s warranty appli
www.allen-heath.com/legal
By using this Allen & Heath product and the software within it you agree to be bound by the terms of the relevant End User Licence Agreement
(EULA), a copy of which can be found at: www.allen-heath.com/legal
Register your product with Allen & Heath online at: http://www.allen-heath.com/support/register-product/
Check the Allen & Heath website for the latest documentation and software updates.
www.allen-heath.com
