Allen-Heath Qu-5D Bruksanvisning

Allen-Heath blandningskonsoler Qu-5D

Läs gratis den bruksanvisning för Allen-Heath Qu-5D (139 sidor) i kategorin blandningskonsoler. Guiden har ansetts hjälpsam av 6 personer och har ett genomsnittsbetyg på 4.8 stjärnor baserat på 3.5 recensioner. Har du en fråga om Allen-Heath Qu-5D eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/139

User Guide

Firmware V1.1 Issue 2


 2

User Guide V1.1 Issue 2

Contents
 Important Information ................................................................ 7
 Introduction ............................................................................. 8
 Updating Firmware .................................................................... 9
1  Update firmware using the Qu-MixPad app .............................. 9
2  Update firmware using a USB drive ....................................... 10
 Connections ........................................................................... 11
1  Power .................................................................................. 11
2  Local Inputs ......................................................................... 11
3  Local Outputs ....................................................................... 12
4  SLink.................................................................................... 13
5  Dante (Qu-5D, Qu-6D, Qu-7D only) .......................................... 13
6  USB and SD Card .................................................................. 14
7  Network ............................................................................... 14
8  Footswitch ........................................................................... 14
 Operation and Workflow ........................................................... 15
1  Powering on and off ............................................................. 15
2  The basic concept ................................................................ 15
3  Channel Types ...................................................................... 16
4  Physical Controls ................................................................. 17
5  Workflow.............................................................................. 18
6  Home Screen........................................................................ 19
 App control ............................................................................ 20
1  Connecting Apps .................................................................. 21
 Mixer setup ............................................................................ 22
1  Strip Assign ......................................................................... 22
