F012TH Wireless Indoor Thermo-Hygrometer User Manual
1. Introduction
Thank you for your purchase of the F012TH Wireless Indoor Thermo-Hygrometer. The following user
guide provides step by step instructions for installation, operation and troubleshooting.
2. Getting Started
Note: The power up sequence must be performed in the order shown in this section (insert batteries
in the remote transmitter(s) first, Display Console second).
Indoor Thermo-Hygrometer Sensor Set Up
1. Remove the battery door on the back of the display, as shown in Figure 1. Insert two AAA
(alkaline or lithium, avoid rechargeable) batteries in the back of the indoor sensor.
Figure 1
After inserting the batteries, All of the LCD segments will light up for a few seconds to verify all seg-
ments are operating properly. and then icon flash once per 60 seconds thereafter. Each time it flashes,
the sensor is transmitting data.
2. Verify the correct channel number (CH) and temperature units of measure (°F vs. °C) are on
the display, as shown in Figure 2.
Page 2
Figure 2
1.
Temperature
2. Temperature units (°F or °C)
3. Temperature, Rate of Change indicator
4. Temperature Calibrated Icon (when the cali-
bration is displayed )
5. Emission Icon (flashes when updating)
6. Humidity, Rate of Change indicator
7. Min/Max Clears daily mode
8.
Low
power
indicator
9. Humidity Calibrated Icon (when the calibration is
displayed )
10. Humidity Comfort Colorful Icon
11. Relative Humidity (%)
12. Channel 1,2,3,4,5,6,7,8 indictor
13. Min/Max Record mode
3. Close the battery door. Put on the table or on the wall.
3. Display Features
3.1 Comfort Colorful Icon
The comfort icon is based on humidity ranges specified in Figure 3.
RH<45%
RH 45%~65%
RH >65%
Page 3
Dry
Comfortable
Wet
Figure 3
3.2 Rate of Change Icon
The rate of change icon detects rapid changes in temperature and humidity. If the arrow points
upward, the temperature is increasing at a rate of +4°F per 30 minutes (or greater), or humidity is in-
creasing at a rate of +5% per 30 minutes (or greater). If the arrow points downward, the temperature is
decreasing at a rate of -4°F per 30 minutes (or less), or humidity is decreasing at a rate of -5% per 30
minutes (or less).
4. Indoor Thermo-Hygrometer Sensor Operation
Note: The indoor sensor has three buttons for easy operation: button, button, MIN/MAX/- SET
and button. CH/+
4.1 Indoor Sensor Channel Setting
Press and hold the button 3 seconds to switch the display scroll mode . In scroll mode, press CH/+
the CH/+ button to set up channel 1 through 8. Press and hold the button 3 seconds to exit channel CH/+
setting. Scroll sign disappears.
Note: BEFORE inserting the receiver batteries, set each indoor sensor channel number FIRST (the
default is Channel 2, Outdoor sensor default is Channel 1) ,The FT012TH supports up to eight trans-
mitters.
4.2 Min/Max Mode
The Min/Max mode displays the minimum and maximum temperature and humidity (since reset of the
unit) for the indoor sensor.
1. . Press the button once to display the maximum. The Display Maximum MIN/MAX MAX
icon will be displayed.
2. To reset the maximum values to the current values, Clear Maximum. press and hold the
MIN/MAX button for 3 seconds.
3. Display Minimum. Press the MIN/MAX button again to display the minimum. The icon MIN
will be displayed.
4. To reset the minimum values to the current values, Clear Minimum. press and hold the
MIN/MAX button for 3 seconds.
To return to normal mode, press the button again. MIN/MAX
4.3 Clearing Min/Max Daily
The minimum and maximum can be set to clear daily (at midnight) or manually. Press and hold the SET
button for 3 seconds to switch between and Clears Manually.
