Version 1.2 ©Copyright 2018, Ambient LLC. All Rights Reserved. Page 1
Ambient Weather WS-0270 Wireless Indoor / Outdoor
Thermometer with Indoor Humidity User Manual
Table of Contents
1 Introduction ..................................................................................................................................... 1
2 Getting Started ................................................................................................................................ 1
2.1 Parts List ................................................................................................................................. 2
2.2 Recommend Tools .................................................................................................................. 2
2.3 Thermometer Sensor Set Up .................................................................................................. 2
2.4 Display Console Set Up ......................................................................................................... 3
2.4.1 Display Console Layout ..................................................................................................... 4
2.4.2 Sensor Operation Verication ............................................................................................ 4
3 Wireless Sensor Installation ............................................................................................................ 4
3.1 Mounting with Zip Tie ........................................................................................................... 5
3.2 Mounting with Nail or Screw ................................................................................................. 5
4 Console Operation........................................................................................................................... 5
4.1 Temperature Units of Measure ............................................................................................... 5
4.2 High Low Record ................................................................................................................... 5
4.3 Sensor Resynchronization ...................................................................................................... 6
4.3.1 Best Practices for Wireless Communication ...................................................................... 6
5 Glossary of Terms ........................................................................................................................... 7
6 Specications .................................................................................................................................. 7
6.1 Wireless Specications .......................................................................................................... 7
6.2 Measurement Specications ................................................................................................... 7
6.3 Power Consumption ............................................................................................................... 7
7 Troubleshooting Guide .................................................................................................................... 7
8 Liability Disclaimer ........................................................................................................................ 8
9 FCC Statement ................................................................................................................................ 9
10 Warranty Information ................................................................................................................. 9
1 Introduction
Thank you for your purchase of the Ambient Weather -0270 Wireless Indoor/Outdoor WS
Thermometer with Indoor Humidity. The following user guide provides step by step instructions for
installation, operation and troubleshooting. To download the latest manual and additional
troubleshooting tips, please visit:
http://AmbientWeather.net/help
2 Getting Started
Note: The power up sequence must be performed in the order shown in this section (insert
batteries in the remote transmitter rst, Display Console second). (s)
The -0270 weather station consists of a display console (receiver), and a thermometer (remote WS
Version 1.2 ©Copyright 2018, Ambient LLC. All Rights Reserved. Page 2
transmitter).
2.1 Parts List
QTY
Item
1
Display Console
Frame Dimensions (LxHxW): 3 x 3.5 x 1 in
LCD Dimensions (LxW): 2.5 x 2.25"
LCD Segment Height: 0.75 inch
1
Thermometer transmitter (WH19)
Dimensions (LxHxW): 2.75” x ”1.75” x 0.75
1
User Manual
2.2 Recommend Tools
Hammer for hanging remote thermometer transmitter.
2.3 Thermometer Sensor Set Up
Note: Do not use rechargeable batteries. They tend to have a lower operating voltage, do not have
a wide temperature range, and do not last as long as non-rechargeable batteries.
We recommend fresh alkaline batteries for outdoor temperature ranges between -4 and 140 °F °F and
fresh lithium batteries for outdoor temperature ranges between -40 140 °F and °F.
1. Remove the battery door on the back of the sensor by sliding the compartment door down, as
shown in Figure 1 .
Figure 1
1
Integrated hanger for zip tie
2
Wireless transmitter LED
3
AA Battery
4
Battery Compartment Cover
2. Insert one AA battery.
3. After inserting the battery, the remote sensor LED indicator will light for 4 seconds, and then
ash once per 60 seconds thereafter. Each time it ashes, the sensor is transmitting data.
4. Close the battery door.
Version 1.2 ©Copyright 2018, Ambient LLC. All Rights Reserved. Page 3
2.4 Display Console Set Up
1. Move the remote thermometer 5 to (s) about 10’ away from the display console (if the sensor
is too close, it may not be received by the display console ).
2. Remove the battery door on the back of the display, as shown in Figure 2. Insert one AA
(alkaline or lithium, avoid rechargeable) battery in the back of the display console.
Figure 2
1
Suspension eye for wall hanging
2
Desk Stand
3
°C / °F button
4
High / Low Record button
5
Battery Compartment
6
Battery Compartment door
All of the LCD segments will light up for a few seconds to verify all segments are operating properly.
3. Replace the battery door, and fold out the desk stand and place the console in the upright
position.
The console will instantly display indoor temperature and humidity. The remote
temperature will update on the display within a few minutes.
While in the search mode, the reception search icon ash.
If the remote does not update, please reference the troubleshooting guide in Section 7.
