Sida 1/40

 OperatingInstruction

D Bedienungsanleitung

FManueld’utilisation

Инструкцияпо

 эксплуатацииинвертера

IIstruzionid‘uso

HHasználatiutasítás

EManualdeinstrucciones

 Instrukcija

 Instrukcija

SAnvändarinstruktioner

Manual

PManualdeInstruões

Gebruiksaanwijzing

Návodkobsluze

Kaasaskantav

Návodnapoužitie

 Navodilazauporabo

Instructiunideutilizare

OδηγίεςΛειτουργίας

Uputstvazaupotrebu







> Lampcomponents:

 Mainlamp:  Halogen6V,6W.

 Energy-savinglamp:  4LED,operatinglife>100,000h.

> Battery:  6xAANiMH,7.2V,2100mAh,rechargeable.

> Chargingtime:  3–3.5h.

> Operatingtime:

 Halogenmainlamp  approx.3hafterwardspossibleswitch-overto4LED>2h

 4LED   approx.120h

> ProtectionclassII.

> Protectivesystem:  IP44.

> Operation/storagetemperature: –20°C-+50°C.



> Beforeoperatingforthefirsttime,fullychargethelamp.

> Fullychargethelamp,beforeputtingawayinstorageforalongerperiodoftime.

> Chargingoptions:

 Plugpowerpack:  100-240V,50/60Hz.

 Automotivechargingplug: 12V-24VDC(max.2A).

Makecertainthatthecigarettelighteralsoremainsvolt-carryingwhentheignitionkeyisremoved.

Shouldthisnotbethecase,thenthechargingleadshouldbeconnectedthrougha3Afusedirectlytothe

vehiclebattery!

> AYELLOWLEDsignalsthatthelampisslowlybeingcharged.

 AREDLEDsignalsthatthelampisbeingchargedonfullpower.

 TheLEDswitchestoGREENassoonasthestoragebatteryischarged.

> Topreservethecharge,thelampshouldalwaysbeparkedinthewallbracketwhenitisnotbeingused.

 Self-dischargeandtherelatedreductionofthecapacityofthestoragebatteryisavoidedinthisway.Theportable

 searchlightisequippedwithanautomaticvoltagechargemonitorÔpermanentchargeispossible!



Pressoperationselectioncontrolpushbutton1x:Themainlampisswitchedon

Pressoperationselectioncontrolpushbutton2x:Energysavinglamp(4LED)isswitchedon

Pressoperationselectioncontrolpushbutton3x:Themainportablesearchlightisswitchedoff

The energy savinglamp(LED)isautomaticallyactivatedwhenthe filament ofthemainlamp breakand

beforethedeepdischargeprotectionisactivated.

One can manually switchover to the energy saving lamp (4LED)before the final discharge voltage is

reached(remaininglightduration>2h).

Theportablesearchlightswitchesitselfoffassoonasthefinaldischargevoltageisreached.

   

Whenoperatingtheportablesearchlight,thebatterycapacityavailablewillbesignaledthrough

1DUOlight-diodes:

1GREENLED: 100%

1REDLED:  <25%

1blinkingLED:Whentheremainingbatterycapacityisreached,itispossibletoswitchovertotheenergy

sparinglamp(remaininglightduration>2h)

rePAIrANdMAINteNANce:

Repairworkmayonlybeperformedbyprofessionallytrainedelectricians!

Onlyoriginalreplacementpartsmaybeused!

Usedbatteriesshouldbedeliveredtorecycling,anddonotbelongwiththehouseholdgarbage!

cONstrUctIONOftHeseArcHlIGHt:

1. Batterycapacitydisplaythrough1DUOLED.

2. Operationselectioncontrolswitch.

3. ChargesocketInput12V-24V.

4. Wallbracket.

5. Searchlightheadwithhalogenlamp.

6. Energysavinglampwith4highperformanceLEDsontheundersideoftheportablesearchlight.

7. Guidehookacceptingadiffusiondisk.(whiteandorange–NOTincludedinthescopeofsupply).

9. Housingwithintegratedlampcontrolsystemandchargingelectronics.

WHeNcHANGINGtHelAMP,PleAsePrOceedAsfOllOWs:

> Openthelampringsbypressingtheswitchonthelampheadupperside

> Carefullyremovethelampringwiththereflector

> Cautiouslyremovethelamp,forwards

> Graspthenewlampwithcloth,andinsertitintotheprescribedopening

> Installthereflector;allthewhilepaycarefulattentionthattheopeningofthegivenlampismountedinhiscorrect

 position

> Whenclosingthelampring,paycarefulattentionthattheswitchhasbeencorrectlyapplied,andthatitispressed

 untilitstops.
