Sida 1/40

 OperatingInstruction

D Bedienungsanleitung

FManueld’utilisation

Инструкцияпо

 эксплуатацииинвертера

IIstruzionid‘uso

HHasználatiutasítás

EManualdeinstrucciones

 Instrukcija

 Instrukcija

SAnvändarinstruktioner

Manual

PManualdeInstruões

Gebruiksaanwijzing

Návodkobsluze

Kaasaskantav

Návodnapoužitie

 Navodilazauporabo

Instructiunideutilizare

OδηγίεςΛειτουργίας

Uputstvazaupotrebu







> Lampcomponents:

 Mainlamp:  Halogen6V,20W.

 Energy-savinglamp:  4LED,operatinglife>100,000h.

> Battery:   6xAANiMH,7.2V,3000mAh,rechargeable.

> Chargingtime:  3–3.5h.

> Operatingtime: 

 Halogenmainlamp  ca.1hafterwardsswitch-overpossibleto4LED>2h

 4LED   approx.200h

> ProtectionclassII.

> Protectivesystem:  IP44.

> Operation/storagetemperature: –20°C-+50°C.



> Beforeoperatingforthersttime,fullychargethelamp.

> Fullychargethelamp,beforeputtingawayinstorageforalongerperiodoftime.

> Chargingoptions:

 Plugpowerpack:  100-240V,50/60Hz.

 Automotivechargingplug: 12V-24VDC(max.2A).

Makecertainthatthecigarettelighteralsoremainsvolt-carryingwhentheignitionkeyisremoved.Shouldthis

notbethecase,thenthechargingleadshouldbeconnectedthrougha3Afusedirectlytothevehiclebattery!

> AYELLOWLEDsignals,precharging

 AREDLEDsignals,charging

 AGREENLEDsignals,fullycharged,andalsocompensationcharge

> Topreservethecharge,thelampshouldalwaysbeparkedinthewallbracketwhenitisnotbeingused.Inthisway,

spontaneousself-discharge,andtherelatedreductioninbatterycapacitywillbeavoided.Theportablesearchlightis

equippedwithamicro-controllercontrolledcharge,Ôpermanentchargeispossible!



Pressoperationselectioncontrolpushbutton1x:Themainlampisswitchedon

Pressoperationselectioncontrolbutton1x,holddepressed:Dimmingfrom100%downto25%andbackto100%

Pressoperationselectionswitch2x:Energysavinglamp(4LED)isswitchedon

Pressoperationselectioncontrolpushbutton3x:Portablesearchlightisswitchedo

Onecanmanuallyswitchovertotheenergysavinglamp(4LED)beforethenaldischargevoltageisreached(remain-

inglightduration>2h).Theportablesearchlightswitchesitselfoautomatically,assoonasthebatterypackis

empty,inordertopreventdamagetothebatterypack.



Whenoperatingtheportablesearchlight,theavailablebatterycapacitywillbesignaledby

4BLUElight-diodes:

4BLUELED:   100%

3BLUELED:   <75%

2BLUELED:   <50%

1BLUELED:   <25%

1blinkingBLUELED:Whentheremainingbatterycapacityisreached,itispossibletoswitchovertotheenergysparing

lamp(remaininglightduration>2h)

Emergencylightfunction:(powerfailureelectronics)

Shouldthepowersupplyfailwhilethelampisparkedinthewallbracketforcharging,themainlampbeginstoburn

untilthesupplyvoltagehasbeenrestoredorthedischargelimitofthebatteryisreached.Itispossibletoswitcho

theportablesearchlightmanually.

Repairandmaintenance:

Repairworkmayonlybecarriedoutbyprofessionallytrainedelectricians!

Onlyoriginalreplacementpartsmaybeused!





> Disengage(2)switches,leftandrightonthebase.

> Removetheoldbattery.

> Insertthenewbattery.

> Re-engagethetwoswitches,leftandrightonthebase.

Usedbatteriesshouldbebroughttorecyclinganddonotbelongwiththehouseholdgarbage!



1. Batterycapacitydisplaythrough4BLUELED.

2. Operationselectioncontrolswitch.

3. ChargesocketInput12V-24V.

4. Wallbracketwithintegratedchargingelectronics.

5. Searchlightheadwithhalogenlamp.

6. Energysavinglampwith4highperformanceLEDsontheundersideoftheportablesearchlight.

7. Colourltersattachmentavailableasanoption.(orangeandred–NOTincludedinthescopeofsupply).

9. Housingwithintegratedlampcontrolsystem.



Pleaseproceedasfollows:

> Openthelampringsbypressingtheswitchonthelampheadupperside

> Carefullyremovethelampringwiththereector

> Cautiouslyremovethelamp,forwards

> Graspthenewlampwithcloth,andinsertitintotheprescribedopening

> Insertthereector,whilepayingcarefulattentionthatthegivenlampisnotdamaged

> Whenclosingthelampring,paycarefulattentionthattheundersideisattachedrst,andthatafterwardsthe

 uppersideispresseduntilitcatches.
