Artsound HPRO550 Bruksanvisning

Artsound högtalare HPRO550

Läs gratis den bruksanvisning för Artsound HPRO550 (4 sidor) i kategorin högtalare. Guiden har ansetts hjälpsam av 17 personer och har ett genomsnittsbetyg på 4.7 stjärnor baserat på 9 recensioner. Har du en fråga om Artsound HPRO550 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/4

ONTDEK HET VOLLEDIGE ARTSOUND AANBOD OP WWW.ARTSOUND.BE

DISCOVER THE COMPLETE ARTSOUND RANGE AT WWW.ARTSOUND.BE

DÉCOUVREZ LA GAMME ARTSOUND COMPLÈTE SUR WWW.ARTSOUND.BE

sa House of Music nv

Ronse, Belgium

  +32 9 380 81 80 +32 9 386 12 35

 ␣ www.artsound.be info@artsound.be

  @Art_Sound ArtSound.Audio

HPRO550

180 200

200

180

HPRO550

elles toutes les deux défectueuses ? Dans ce cas,

mieux vaut vériﬁ er votre ampliﬁ cateur.

• L'enceinte/les enceintes émet(tent) des craque-

ments.

• Si vous enfoncez légèrement le moteur de l'enceinte

(woofer), celui-ci frotte-t-il ?

De la sorte, votre revendeur saura dans quelle direc-

tion s'orienter pour poser son diagnostic. Merci de

votre collaboration.

FICHE TECHNIQUE

• système : 2 voies coaxial

• woofer : 5,25” cône alu. bord caoutchouc

• tweeter : 2 x 0,75” dôme néodyme alu.

• puiss. amp. recomm. : 10 -100 W

• sensibilité : 88 dB

• impédance : 8 Ω

• plage de fréquences : 60 Hz - 20 kHz

• dim. de découpe (Ø) : 180 mm

• dimensions (Ø x d) : 200 x 80 mm

• poids / pièce : 1,10 kg

• coleur : blanc

• propriétés : peut être peint,

résistant aux éclaboussures

• options : grille noire (GRILL RO525 B),

kit acoustique (KITRO2)

GARANTIE

2 ans à partir de la date d'achat, dans le cadre d'une

utilisation normale. Les conditions de la facture

s'appliquent.

EN Dear Customer, Congratulations on the purchase

of your loudspeaker(s). Please read these instructions

carefully and keep them for future reference.

INSTALLATION (FIG 2 PAG.2)

1 Remove the inwall speaker from the box. In the box,

you will ﬁnd a stencil. Hold the stencil to the spot

where you want to mount the loudspeaker, and

using the pencil, draw an outline along the edge of

the stencil.

2 Drill one or more holes along the inside edge of the

pencilled-in line. For square or rectangular spea-

kers, it is easier to drill four holes, whereas for a

round speaker one hole is probably sufﬁcient.

3 Using the jig saw, saw along the edge so that you are

left with a nice, round, square or rectangular hole.

4 Now hold the inwall speaker tight. You can remove the

grille by simply pulling on it. Only the magnet holds

it in place.

5 Pull the clamps back in and turn them all inward. Con-

nect the loudspeaker cable. If you forget to do this,

you will have to remove it again later!

6 Place the inwall speaker in the hole. Tighten the

screws. This will cause the clamps at the back to

automatically turn back outwards so that the loud-

speaker will lock in place.

7 If you like, you can also paint the grill with spray

paint.

8 If you would like to remove the loudspeaker or paint

the grill, you must remove the grill ﬁrst. You can do

this by simply pulling on it. Only the magnet holds

it in place.

TROUBLESHOOTING

Should you experience problems, please contact your

certiﬁ ed dealer. He or she will ask you several speciﬁ c

questions. In order to be able to answer these ques-

tions, please check the following in advance:

• You can’t hear any sound; in other words, the loud-

speaker is either no longer producing sound, or is only

playing the high or low tones.

• Is the other loudspeaker still producing sound? Or are

both of them defective? If so, it is best to check your

ampliﬁ er.

• The loudspeaker(s) is (are) cracking.

• If you lightly press the loudspeaker driver (woofer), is

there any friction?

If you know the answers to these questions in advance,

your dealer will be better able to help you in diagnosing the

problem. Thank you in advance for your cooperation.

TECHNICAL SPECIFICATIONS

• system : 2-way coaxial

• woofer : 5,25” aluminium cone rubber edge

• tweeter : 2 x 0,75” neodymium alu dome

• amp power : 10 - 100W (recommended)

• sensitivity : 88dB

• impedance : 8 Ω

• frequency range : 60Hz - 20kHz

• dimensions cut-out (Ø) : 180mm

• dimensions (Ø x d) : 200 x 80mm

• weight / piece : 1,10kg

• colour : white

• composition : paintable, water repellent

• options : black grill (GRILL RO525 B),

acoustic kit (KITRO2)

WARRANTY

2 years after date of purchase for normal use.

Invoice terms and conditions apply.

Produktspecifikationer

Varumärke:	Artsound
Kategori:	högtalare
Modell:	HPRO550
Vikt:	1100 g
Bredd:	200 mm
Djup:	80 mm
Höjd:	200 mm
Rekommenderad användning:	Hem
Impedans:	8 Ω
Ljudutgångskanaler:	- kanaler
Högtalarplacering:	Ceiling-monterbar
Antal förare:	3
Bashögtalare:	Ja
Känslighet:	88 dB
Produktens färg:	Black, White
Uteffekt (RMS):	100 W
diskanthögtalare:	Ja
Material, hölje:	Acrylonitrile butadiene styrene (ABS), Aluminium
Magnetmaterial:	Neodymium
Frekvensområde:	60 - 20000 hz
Anslutningsteknologi:	Kabel
Woofer diameter:	133.35 mm
Woofer diameter (imperial):	5.25 "
Högtalartyp:	2-vägs
Antal woofer-drivenheter:	1
Disktanthögtalare diameter:	0.75 "
Antal tweeter förare:	2
Rekommenderad förstärkareffekt (min):	10 W
Driver Konmaterial:	Gjuten aluminium
Rekommenderad förstärkareffekt (max):	100 W
