Artsound R8 Bruksanvisning

Artsound Radio R8

Läs gratis den bruksanvisning för Artsound R8 (20 sidor) i kategorin Radio. Guiden har ansetts hjälpsam av 25 personer och har ett genomsnittsbetyg på 4.9 stjärnor baserat på 13 recensioner. Har du en fråga om Artsound R8 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/20

ArtSound R8

Internet / DAB+ radio

OPERATING MANUAL

TABLE OF CONTENTS

1. Warnings and safety 2

2. Contents of the box 2

3. Location of Controls 2

4. Remote control 3

5. How to input password for

your wireless network 4

6. Before you start 4

7. Getting started 4

8. Charging battery 5

9. Network Setup 5

10. Overview of features and functions 6

11. Internet Radio 6

12. Media Centre 8

13. DAB+/DAB Radio 8

14. FM Radio 9

15. Bluetooth playback 9

16. Alarm Setting 10

17. Sleep Timer Setting 10

18. Conﬁguration 10

19. Remote control via PC / Smart phone

Tuning internet radio & manage favour-

ite 14

20. Trouble Shooting 16

21. Helpful Tips 17

22. Technical Speciﬁcation 18

23. Warranty conditions 19

2. CONTENTS OF THE BOX

• ArtSound R8 radio

• Power adaptor

• Remote control (without batteries)

• User manual

3. LOCATION OF CONTROLS

1. WARNINGS AND SAFETY

• To prevent ﬁre or electric shocks, the device must not be exposed to rain or humidity.

• For your own safety: to prevent electric shocks do not remove the housing.

• Do not try to repair any malfunctioning parts of the device yourself. Ask a professional expert to do this for you.

• When plugged into the mains, the device remains electrically charged even when switched o.

Thank you for buying our ArtSound R8 radio. We hope you’ll enjoy it for years to come. Please read these instruc-

tions carefully and keep this manual for later reference.

The R8 is a high-quality internet, DAB+ and FM radio with Bluetooth and a built-in rechargeable battery.

SCROLL / SELECT

10 9 8 7

11 12 13 14 15

LED

Reset

DC 5V

4. REMOTE CONTROL

1. Press and hold to power on/o

Press and release to Standby / activate the radio

(Standby is enabled only when power is con-

nected. It will be disabled when internal battery

is used)

Back to previous menu/left cursor

3. ⊲ Right cursor/Enter edit menu under Favourite

list /View the big clock & radio info under playing

screen

4. Press to enter the alarm setting (Alarm 1 and

Alarm 2)

Access Home screen/press this button to return

to the playing screen

Press and hold to preset a particular station

Press to recall the favourite list

Rotate to adjust the volume level

8. Scroll / Select

Rotate to scroll along, up/down on the menu Press

in to conﬁrm / Select menu options

Press in to stop / resume playback of radio chan-

nel

9. TFT color screen 2.4"

10. Speaker

11. Earphone jack 3.5 mm

12. Reset pin hole

13. LED indicator for battery charging

14. DC IN Jack

15. Telescopic antenna

Press to toggle between Standby and Operation

(applicable only when Standby is enabled with power

connected to the radio)

Mute

0-9 Input index number on the list / input characters for

WiFi password

Preset the current playing station to Favorite

▲ Cursor up

⊳ Cursor left / back to previous menu

Alarm button

Sleep Timer

Mode Switch between radio modes

Home

 Previous station on the list/previous track on blue-

tooth/Media Centre

Local Access the local station list (Local area set up in

Conﬁguration)

Recall the favorite list

OK conﬁrm button

⊲ Cursor right

▼ Cursor down

Vol+ Volume up

Vol- Volume down

EQ Equalizer

 Next station on the list/next track on bluetooth/Media

Centre

 Play/pause for Bluetooth/Media Centre Play/stop for

Internet radio

Dimmer Access the Dimmer menu to adjust the brightness

of the display

Info Quick access to Network and System information

Produktspecifikationer

Varumärke:	Artsound
Kategori:	Radio
Modell:	R8
Inbyggd display:	Ja
Vikt:	890 g
Bredd:	115 mm
Djup:	110 mm
Höjd:	186 mm
Batterikapacitet:	2200 mAh
Skärm diagonal:	2.4 "
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth-version:	4.2
Frekvensband:	DAB+, FM
Inbyggda högtalare:	Ja
Volymkontroll:	Röra
Hörlursutgångar:	1
Material:	ABS, Wood
Typ av tuner:	Digital
Väckarklocka:	Ja
Batteriteknik:	Litium-Ion (Li-Ion)
Produktens färg:	Svart
Uteffekt (RMS):	- W
Nätverksansluten (Ethernet):	Ja
Strömkälla:	Batteri
Bluetooth:	Ja
Antenntyp:	Extern
Klocka:	Ja
Drifttid för batteri:	4 h
Antalet förinställda stationer:	99
Typ av radio:	Internet
Internetradio tjänster som stöds:	Spotify
Projicering:	Nej
