Sida 1/20
1
ArtSound R99
Internet Radio Tuner
OPERATING MANUAL
TABLE OF CONTENTS
1. Warnings and safety 2
2. Contents of the box 2
3. Location of Controls 2
4. Remote control 3
5. Entering security code for your
wireless network 4
6. Before you start 4
7. Getting started 4
8. Network Setup 4
9. Overview of features and functions 6
10. Internet Radio 6
11. Media Centre 9
12. USB playback 9
13. DAB+/DAB Radio 10
14. FM Radio 10
15. Bluetooth playback 11
16. Alarm Setting 11
17. Sleep Timer Setting 12
18. Configuration 12
19. Web browser control via PC / Smart phone
Tuning internet radio & manage favourite 15
20. Trouble Shooting 17
21. Helpful Tips 19
22. Technical Specification 19
23. Warranty conditions 19
R99
2
2. CONTENTS OF THE BOX
• Internet Radio Tuner
• Power adaptor
• Wire antenna
3. LOCATION OF CONTROLS
1. WARNINGS AND SAFETY
• To prevent fire or electric shocks, the device must not be exposed to rain or humidity.
• For your own safety: to prevent electric shocks do not remove the housing.
• Do not try to repair any malfunctioning parts of the device yourself. Ask a professional expert to do this for you.
• When plugged into the mains, the device remains electrically charged even when switched o.
Thank you for buying our ArtSound R99 radio. We hope you’ll enjoy it for years to come. Please read these
instructions carefully and keep this manual for later reference.
The R99 is a high-quality internet, DAB+ and FM radio with Bluetooth and stereo audio output and input.
1. Power
Press to enter/exit from Standby mode
2. Power LED
Lit when DC-in has valid power
3. Tune/Select
Rotate to navigate menu
Rotate to adjust volume of headphone
Press to select an item
4. Dedicated Preset button No.1-4
Press and hold to preset 4 dedicated stations.
Press briefly to recall to play. These are inde-
pendent presets and will not appear on the "My
Favorite" list.
5. FAV
Press and hold to preset the favorite stations up to
150. Press it briefly to recall the list.
6. ⊲ (FORWARD)
Press to cycle through the display option in radio
playing mode / Enter edit menu in Favourite list /
cursor right
7. ⊳ BACK
Press to exit to previous menu / delete entry of
character's input/ cursor left
8. INFO
Toggle to cycle through the station's info, the big
clock display or return to now playing screen
9. HOME
Press to display Home screen to view dierent
radio modes / setting options
10. 2.4”TFT color display
11. IR sensor
Receives Infra red signal from remote control
• External antenna x 2 pcs
• RCA cable
• Remote control (without batteries)
• User manual
R99
3
4. REMOTE CONTROL
Mute
0-9 Input index number on the list / input characters for
WiFi password
Preset the current playing station to Favorite
▲ Cursor up
⊳ Cursor left / back to previous menu
Alarm button
Sleep Timer
Mode Switch between Internet radio/DAB/FM/Bluetooth/
Media Centre
Main Menu
Previous station on the list/previous track on blue-
tooth/Media Centre
w Access network info of the radio unit
Press to toggle between Standby and Operation
Recall the favorite list
OK confirm button
⊲ Cursor right
▼ Cursor down
Vol+ Volume up
Vol- Volume down
EQ Equalizer
Next station on the list/next track on bluetooth/Media
Centre
Play/pause for Bluetooth/Media Centre Play/stop for
Internet radio
Dimmer Access the Dimmer menu to adjust the brightness
of the display
Info Toggle to cycle through the station's info, the big
clock display or return to now playing screen
12. USB Playback
Play audios from USB thumb drive
13. Headphone jack
3.5 mm Headphone output with volume controlled
by dial (for the line output volume control, please
refer to the Line/Digital out setting on P.15)
14. Power On/O switch
15. DC-IN Jack
16. Ethernet (LAN) connector
17. WiFi antenna connector
Connect the WiFi antenna before setting up the
Tuner
18. DAB/FM antenna
19. Digital out – Optical
20. Digital out - Co-axial
21. Line out - L
22. Line out - R
23. BT Antenna connector
Connect the Bluetooth antenna before pairing
with your bluetooth
