Sida 1/20

ArtSound R8

Internet / DAB+ radio

OPERATING MANUAL

TABLE OF CONTENTS

1. Warnings and safety 2

2. Contents of the box 2

3. Location of Controls 2

4. Remote control 3

5. How to input password for

your wireless network 4

6. Before you start 4

7. Getting started 4

8. Network Setup 4

9. Overview of features and functions 6

10. Internet Radio 6

11. Media Centre 8

12. DAB+/DAB Radio 8

13. FM Radio 9

14. Bluetooth playback 9

15. Aux-In 10

16. Alarm Setting 10

17. Sleep Timer Setting 10

18. Conﬁguration 11

19. Remote control via PC / Smart phone

Tuning internet radio & manage

favourite 14

20. Trouble Shooting 16

21. Helpful Tips 17

22. Technical Speciﬁcation 18

23. Warranty conditions 19

2. CONTENTS OF THE BOX

• ArtSound R9 radio

• Power adaptor

• Remote control (without batteries)

• User manual

3. LOCATION OF CONTROLS

1. WARNINGS AND SAFETY

• To prevent ﬁre or electric shocks, the device must not be exposed to rain or humidity.

• For your own safety: to prevent electric shocks do not remove the housing.

• Do not try to repair any malfunctioning parts of the device yourself. Ask a professional expert to do this for you.

• When plugged into the mains, the device remains electrically charged even when switched o.

Thank you for buying our ArtSound R9 radio. We hope you’ll enjoy it for years to come. Please read these instruc-

tions carefully and keep this manual for later reference.

The R9 is a high-quality internet, DAB+ and FM radio with Bluetooth and stereo audio output and input.

12 11

1 2

5 6

4. REMOTE CONTROL

1. Power

Standby on/o

2. Left arrow

Back to previous menu/left cursor

3. Right arrow

Right cursor/Enter edit menu under Favourite list /

View the big clock & radio info under playing screen

4. Local

Access the internet station locally

5. Favourite

Press and hold to preset particular station to

favourite list Press to recall the favourite list

6. Menu

Access main menu/press this button to return to

the playing screen

7. Tune/Select/ Volume

[Dial / Select]: Rotate to scroll up / down on the

main menu / Push to conﬁrm / select menu options

/ Push to stop / resume playback of radio channel

[Volume control]: Rotate the knob to adjust volume

level in playing screen

8. TFT 2.4” color screen

9. Infrared sensor for remote

10. Speaker

11. Power on/o switch

12. Earphone jack 3.5 mm

13. Audio out jack 3.5 mm

14. Aux in jack 3.5 mm

15. Ethernet (LAN) connector

16. DC IN Jack

17. Telescopic antenna

Mute

0-9 Input index number on the list / input characters for

WiFi password

Preset the current playing station to Favorite

▲ Cursor up

⊳ Cursor left / back to previous menu

Alarm button

Sleep Timer

Mode Switch between Internet radio/DAB/FM/Bluetooth/

Media Centre

Main Menu

 Previous station on the list/previous track on blue-

tooth/Media Centre

Local Access the local station list (Local area set up in

Conﬁguration)

Press to toggle between Standby and Operation

Recall the favorite list

OK conﬁrm button

⊲ Cursor right

▼ Cursor down

Vol+ Volume up

Vol- Volume down

EQ Equalizer

 Next station on the list/next track on bluetooth/Media

Centre

 Play/pause for Bluetooth/Media Centre Play/stop for

Internet radio

Dimmer Access the Dimmer menu to adjust the brightness

of the display

Info Quick access to Network and System information

Produktspecifikationer

Varumärke:	Artsound
Kategori:	Radio
Modell:	R9
Inbyggd display:	Ja
Vikt:	1200 g
Bredd:	115 mm
Djup:	165 mm
Höjd:	295 mm
Skärm diagonal:	2.4 "
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth-version:	4.2
Frekvensband:	DAB+, FM
Inbyggda högtalare:	Ja
Volymkontroll:	Röra
Hörlursutgångar:	1
Material:	ABS, Wood
Typ av tuner:	Digital
Väckarklocka:	Ja
Produktens färg:	Svart
Uteffekt (RMS):	- W
AC-inspänning:	100 - 240 V
Nätverksansluten (Ethernet):	Ja
Bluetooth:	Ja
Antenntyp:	Extern
Klocka:	Ja
Antalet förinställda stationer:	99
Typ av radio:	Internet
Internetradio tjänster som stöds:	Spotify
Likströmsdriftspänning:	9 V
Projicering:	Nej
