4K/UHD HDMI Over 100M

HDBaseT TX/RX with Ethernet,

Control, and PoE

AT-UHD-EX-100CE-TX & AT-UHD-EX-100CE-RX

AT-UHD-EX-100CE-KIT

atlona.com

Toll free: 1-877-536-3976

Local: 1-408-962-0515

1. Introduction ................................................................................... 3

2. Package Contents ................................................................................... 3

3. Features ................................................................................... 3

4. Before You Start ................................................................................... 3

5. Category Cable ................................................................................... 4

6. Panel Descriptions

a. Front Panel ................................................................................... 5

b. Rear Panel ................................................................................... 6

7. Captive Screw Connectors ................................................................................... 7

8. Connection Diagram ................................................................................... 8-9

9. Specifications ................................................................................... 10

10. Safety Information ................................................................................... 11

atlona.com

Toll free: 1-877-536-3976

Local: 1-408-962-0515

Table of Contents

atlona.com

Toll free: 1-877-536-3976

Local: 1-408-962-0515

Introduction

Pass through support of 4K (UHD), 2560x2048, IR, RS-232, bi-directional Ethernet, and lossy/lossless

audio signals up to 328ft (100m). The 100CE extenders provide an affordable, high quality, solution

for your audio and video needs.

Package Contents

Kit

Features

• 1 x AT-UHD-EX-100CE-TX

• 1 x AT-UHD-EX-100CE-RX

• 1 x 48V DC power supply

• 5 x Female captive screw connector (2 pin (x1): power, 3 pin (x2): RS-232, and 5 pin (x2): IR)

• 2 x Pair of wall/table mount ears

• 2 x Pair of screws for wall/mount ears

• 1 x IR emitter (AT-IR-CS-TX)

• 1 x User manual

• 1 x AT-UHD-EX-100CE-RX

• 1 x 48V DC power supply

• 2 x Female captive screw connector (3 pin: RS-232 and 5 pin: IR)

• 1 x Pair of wall/table mount ears

• 1 x Pair of screws for wall/mount ears

• 1 x IR emitter (AT-IR-CS-TX)

• 1 x User manual

• 1 x AT-UHD-EX-100CE-RX

• 2 x Female captive screw connector (3 pin: RS-232 and 5 pin: IR)

• 1 x Pair of wall/table mount ears

• 1 x Pair of screws for wall/mount ears

• 1 x IR emitter (AT-IR-CS-TX)

• 1 x User manual

• Extends IR, RS-232, Ethernet, and audio/visual content up to 328ft over a single category cable

• Supports resolutions up to 4K (UHD) 60Hz @ chroma sub-sampling 4:2:0 8-bit

• IR ports for use with IR remote controls and 3rd party IR controllers

• Bi-directional Ethernet pass through

• Provides PoE (Power over Ethernet)

• Multichannel audio pass through up to Dolby TrueHD, DTS-HD Master Audio, and Dolby Atmos

• Full 3D pass through

• HDCP 2.2 compliant

• Field updatable firmware

Before You Start

• When installing the extenders DO NOT:

Cover the vents

Install into a sealed wall

Install into an area without adequate air ventilation

Produktspecifikationer

Varumärke:	Atlona
Kategori:	AV extender
Modell:	AT-UHD-EX-100CE-RX
Vikt:	390 g
Bredd:	119 mm
Djup:	89 mm
Höjd:	27 mm
Färg:	Ja
Videolägen som stöds:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Maximal upplösning:	4096 x 2160 pixlar
Certifiering:	CE, FCC
HDCP:	Ja
Modell:	AV-mottagare
Färgdjup:	12 bit
Uteffekt:	0.83 A
Bandbredd:	10.2 Gbit/s
Antal HDMI-utgångar:	1
RJ-45 ingångsportar:	1
HDBaseT-port:	Ja
Kabeltyper som stöds:	Cat5e, Cat6, Cat6a, Cat7
Produktens färg:	Svart
Strömförbrukning (vanlig):	12 W
Temperatur vid drift:	0 - 50 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	20 - 90 %
AC-inspänning:	100-240 V
Anslutningsteknologi:	Kabel
Nätverksansluten (Ethernet):	Ja
Växelström Frekvens:	50 - 60 hz
Max uppdateringsfrekvens:	60 hz
Maximal överföringshastighet avstånd:	100 m
Fjärrstyrd IR-utgång:	1
Fjärrstyrd (IR) ingång:	1
RS-232-ingångar:	1
Arbetsspänning (mottagare):	48 V
