ATOLL ELECTRONIQUE
OWNER’S MANUAL ~ AMPLIFIERAM100 Sig
ATOLL ELECTRONIQUEPage 5Page 4
1) Amplifier input.
2) Amplifier output (to another power
amplifier for bi-amp).
3) Right channel output.
4) Trigger 12V input
(1)
.
5) Left channel output.
6) General power plug and ON/OFF
switch (with internal fuse).
7) Power indicator led.
CONNECTING
DETAILS OF FUNCTIONS
12354
7
(1)
Trigger input: This input allows the control ON/OFF of your
amplifier simultaneously to any device with a 12V Trigger
outlet. In order that the system is operating, the ON/OFF
button of your Amplifier must remain in position OFF (0). If
the switch is in the ON position (I), the amplifier will work but
not the Trigger function.
Trigger cable must be a Male to Male stereo jack plug Ø 3,5 mm (1/8”).
To transform your Power Amplifier from Stereo to Mono, you have to push the switch
a
placed inside the appliance as shown below:
Internal view.
MONO BRIDGE MODE
Warning: for the AM100 Signature, bridged mono mode is not recommended on
speakers with an impedance of less than 6 .Ω
Warning: be sure
that your amplier
is unplugged
and that no other
appliance is plug
in during this
operation.
(Configuration: 1 Preamplifier and 2 mono amplifiers).
CONNECTING
PREAMP
AMP 2
AMP 1
a
LEFT
Jack
Ø 3,5 mm
DO NOT
OPEN
NE PAS
OUVRIR
SERIAL NUMBER
NUMERO DE SERIE
MADE IN FRANCE
FABRIQUE EN FRANCE
DO NOT
OPEN
NE PAS
OUVRIR
SERIAL NUMBER
NUMERO DE SERIE
MADE IN FRANCE
FABRIQUE EN FRANCE
DO NOT
OPEN
NE PAS
OUVRIR
SERIAL NUMBER
NUMERO DE SERIE
MADE IN FRANCE
FABRIQUE EN FRANCE
L
R
PRE-OUT
L
R
AMPLI
INOUT
L
R
AMPLI
INOUT
+–
POWER
POWER
IGHT
+
IGHT
+
LEFT
+
LEFT
+
+–
6
