Sida 1/2

METRA. The World’s best kits.™ metraonline.com1-800-221-0932

Installation Instructions for AX-ADXSVI-GM3

REV. 1/8/2014 INSTAX-ADXSVI-GM3

PONTIAC

Aztec 2001-2005

Grand Am 2001-2005

Grand Prix 2004-2008

Montana SV6 2005-2008

Montana* 2000-2005

Sunfire 2000-2005

SAAB

9-7X 2005-2009

SATURN

Relay 2005-2007

(continued on next page)

AX-ADXSVI-GM3

APPLICATIONS APPLICATIONS

BUICK

Allure 2005-2009

Century 2004-2005

Lacrosse 2005-2009

Rainier 2004-2007

Regal 2004

Rendezvous 2002-2007

Terraza 2005-2008

CADILLAC

Escalade 2003-2006

(only to be used when replacing an

amplified system)

Escalade EXT and ESV 2003-2006

(only to be used when replacing an

amplified system)

CHEVROLET

Avalanche 2003-2006

Cavalier 2000-2005

Colorado 2004-2012

Corvette 2005-2013

(only to be used when replacing an

amplified system)

Express 2003-2007

Impala 2000-2005

Kodiak C4500-C8500 2003-2009

Malibu 2001-2003

Malibu (classic) 2004-2005

Monte Carlo 2000-2005

Silverado pickup (classic) 2007

Silverado pickup (all) 2003-2006

SSR 2003-2006

Suburban 2003-2006

Tahoe 2003-2006

Trailblazer 2002-2009

Uplander 2005-2008

Venture* 2000-2005

GMC

Canyon 2004-2012

Envoy 2002-2009

Savanna 2003-2007

Sierra (classic) 2007

Sierra 2003-2006

TopKick C4500-C8500 2005-2009

Yukon/Yukon XL 2003-2006

HUMMER

H2 2003-2007

(only to be used when replacing an

amplified system)

H3/H3t 2006-2010

ISUZU

Ascender 2003-2008

H-Series 2003-2008

l-Series pickups 2006-2008

OLDSMOBILE

Alero 2001-2004

Bravada 2002-2004

Intrigue 2002

Silhouette* 2000-2004

KIT FEATURES

• Providesaccessory(12volt10amp)

• RetainsR.A.P.(retainedaccessorypower)

• Usedinnon-amplifiedsystemsorwhenreplacingamplifiedsystem

• ProvidesNAVoutputs(parkingbrake,reverse,andV.S.S.)

• PrewiredASWC-1harnessincluded(ASWC-1soldseparately)

• Highlevelspeakerinput

• USBupdatable

Note:

1)ThisharnessmustbeusedinconjunctionwiththeAX-ADXSVI

2)Allchimeswillbelostwhenusingthisharness

Except for those models marked with an “ ”

AX-ADXSVI-GM3

METRA. The World’s best kits.

™

metraonline.com1-800-221-0932

WIRING THE AX-ADXSVI-GM3

• ConnecttheYellowwiretotheradio’s12voltbatteryormemorywire.

• ConnecttheBlackwiretotheradio’sgroundwire.

• ConnecttheRedwiretotheignitionwireoftheaftermarketradio.

• ConnecttheOrange wiretotheilluminationwireoftheaftermarketradio.Ifthe

aftermarketradiohasnoilluminationwire,tapeofftheOrange wire.

• TheOrange/White wirewillnotbeusedinthisapplication.Tapeuporcapoff

thiswireanddisregardit.

• ConnecttheBluewiretotheantennaturnonwireoftheaftermarketradio.

• ConnecttheWhitewiretotheleftfrontpositivespeakeroutputofthe

aftermarketradio.

• ConnecttheWhite/Blackwiretotheleftfrontnegativespeakeroutputofthe

aftermarketradio.

• Connectthe Gray wiretotherightfrontpositivespeakeroutputofthe

aftermarketradio.

• ConnecttheGray/Blackwiretotherightfrontnegativespeakeroutputofthe

aftermarketradio.

• ConnecttheGreen wiretotheradio’sleftrearpositivespeakeroutput.

• ConnecttheGreen/Blackwiretotheradio’sleftrearnegativespeakeroutput.

• ConnectthePurplewiretotheradio’srightrearpositivespeakeroutput.

• ConnectthePurple/Blackwiretotheradio’srightrearnegativespeakeroutput.

Thefollo

wingwiresarefortheaftermarketradiosthathavenavigationbuiltin.

• ConnecttheLight Greenwiretotheparkingbrakewireoftheaftermarketnavigation

radio(ifapplicable).

• Connectthe Blue/Pink wiretotheVSSorspeedsensewireoftheaftermarket

navigationradio(ifapplicable).

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians

IMPORTANT WARNING

Thisproductincludesinstructionsforinstallationwhichmustbecarefullyfollowed.The

instructionsarewordedinsuchamannertoassumethattheinstalleriscapableof

completingthesetypeofelectronicinstallations.Ifyouareunclearastowhatyouare

instructed to do or believe that you do not understand the instructions so as to properly

and safely complete the installation you should consult a technician who does have this

knowledge and understanding.

Failure to follow these instructions carefully and to install the interface as described

could cause harm to the vehicle or to safety systems on the vehicle. Interference with

certain safety systems could cause harm to persons as well. If you have any questions

in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.

• ConnecttheGreen/Purplewiretothereversewireoftheaftermarketnavigation

radio(ifapplicable).

• Cyclethekey,byturningtheignitiononfor30seconds.Thenoffandonagainto

testtheradio.

ASWC-1 (if installing)

AftertheXSVIisinitialized,plugintheASWC-1intothe12-pinharnessofthe

AX-ADXSVI-GM3andrefertotheASWC-1instructions.
