Installation instructions for part AXRC-GM5
REV. 1/21/2020 INSTAXRC-GM5
axxessinterfaces.com
•
metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Axxess Integrate
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
Connections to be made ............................................2
Installing the AXRC-GM5 ...........................................3
Initializing the AXRC-GM5 .........................................3
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse,
and speed sense)
• Used in both amplified and non-amplified sound
systems
• Used in models without OnStar
• Retains all warning chimes
• High level speaker input
• Retains balance and fade
• Micro “B” USB updatable
INTERFACE FEATURES
• Wire cutter • Crimp tool • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
TOOLS REQUIRED
AXRC-GM5
GM Data Bus Interface
2005-2006
APPLICATIONS
• AXRC-GM5 interface • AXRC-GM5 harness
INTERFACE COMPONENTS
Table of Contents
CHEVROLET
Equinox 2005-2006
OLDSMOBILE
Torrent 2006
AXRC-GM5
2
Connections to be made
From the AXRC-GM5 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
• Connect the Blue/White wire to the amp turn-on wire.
• If the aftermarket radio has an illumination wire, connect the Orange
wire to it.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative speaker output.
The following (3) wires are only for multimedia/navigation radios that
require these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
