INSTALLATION INSTRUCTIONS FOR PART AXTO-MI1
METRA. The World’s best kits.™ metraonline.com1-800-221-0932
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 1/21/2020 INSTAXTO-MI1
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
• Retains the factory amplifier
• Provides multimedia wires (parking brake, reverse, and speed sense)
• RCA level input
• Retains balance and fade
• Eliminates “COM ERROR” message on display
FEATURES
• Cutting tool • Crimping tool • Tape • Small
flat-blade screwdriver • Connectors (example:
butt-connectors, bell caps, etc.)
TOOLS REQUIRED
Mitsubishi amplifier interface
2006-2012
AXTO-MI1
APPLICATIONS
• AXTO-MI1 interface • AXTO-MI1 harness
• 14-pin harness with stripped leads and RCA jacks
• 2-pin harness with stripped leads
INTERFACE COMPONENTS
MITSUBISHI
Eclipse 2006-2012
Endeavour 2007-2011
Galant 2007-2012
AXTO-MI1
2
From the 14-pin harness to the aftermarket radio:
• Tape off and disregard the Red wire, it will not be used in this application.
• Connect the Blue/White wire to the amp turn on wire (this wire must be
connected to hear sound from the factory amplifier).
• Tape off and disregard the Brown wire, it will not be used in this application.
• Connect the White RCA to the left front output.
• Connect the Gray RCA to the right front output.
• Connect the Green RCA to the left rear output.
• Connect the Purple RCA to the right rear output.
Note: If the radio does not have RCA outputs, or only one pair, use a line level
convertor (sold separately). Use Axxess part number AXLOC4-80A (4 channel) or
AXLOC-80A (2 channel) for best results.
The following wires are for aftermarket multimedia/navigation radios that provide
these wires (if not required, tape them off and disregard them):
• Connect the Light Green wire to the parking brake wire.
• Connect the Blue/Pink wire to the speed sense/VSS wire.
• Connect the Green/Purple wire to the reverse wire.
Note: Reverse wire is not available on manual transmission vehicles.
Note: To retain these wires, please follow the steps under: From the 2-pin
harness to the vehicle.
• Plug the 14-pin harness into the AXTO-MI1.
From the AXTO-MI1 harness:
(a) to the vehicle:
• Connect the Black wire with a fork connector to chassis ground.
(b) to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
• Connect the Blue wire to the power antenna turn-on wire.
• Connect the Orange wire to the Illumination wire (if the aftermarket radio has
no Illumination wire, tape off the Orange wire).
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative speaker output.
• Connect the 20-pin harness into the AXTO-MI1.
• Connect the 16-pin and 22-pin harness into the vehicle.
Connections to be made
