www.bakerspride.com | p: (800) 527-2100 265 Hobson St. • Smithville, TN 37166

FEATURES AT A GLANCE

akers Pride

EB series pizza ovens are ideal

for high-volume restaurants, oering the

same durability and performance as our gas

deck ovens but with the low maintenance

of an electrical system. The independently

controlled, U-shaped heating elements

on top and bottom allow for uniform

temperatures and perfectly balanced

baking. Each oven chamber has one steel

deck with an 8" deck height. Choose from

two dierent deck sizes and overall widths

(55" or 74").

This series is constructed with heavy-duty

angle iron frame, which is fully welded to

allow for stacking up to three ovens to

increase production without sacriﬁcing

space. Oven exteriors are all heavy-duty,

stainless steel and are fully insulated for

cooler outer temperatures and consistent

interior temperatures.

Options are available to accommodate the

conﬁguration of your kitchen, such as side-

mounted controls for added mobility and

legs with casters..

SERIES: EB

SUPERDECK SERIES 8" DECK HEIGHT ELECTRIC OVENS

• 8,000 or 12,000 watts in

various voltages (see back)

• 150–550°F (65–287°C) bake

thermostat

• Stackable

• Choose overall width: 55" (1397

mm) or 74" (1880 mm)

• Choose deck area: 38" x 36"

(965 x 914 mm) or 57" x 36"

(1448 x 914 mm)

• Steel deck

• 8" (203 mm) deck height

• Heavy-duty, slide-out ﬂame

diverters

• 60-minute timer

• Independently controlled top

and bottom heat dampers

• All stainless steel exteriors,

aluminized steel interiors

• Spring-balanced, fully insulated

doors

• Heavy-duty steel legs ﬁnished

with durable Bakertone

• Fully insulated throughout

• One-year limited warranty

• 440–480 V

• Five-hour timer

• Deck brush and scraper (48"

(1219 mm) long with wood

handle)

• Stainless steel wood chip box

• Legs with casters

• Cordierite or Lightstone decks

OPTIONS & ACCESSORIES

2M-Z25358 REV A (07-23)

www.bakerspride.com | p: (800) 527-2100 265 Hobson St. • Smithville, TN 37166

EQUIPMENT DIMENSIONS

MECHANICAL SPECIFICATIONS

Model #

Overall Dim••

(W x H x D)

Deck

Height

Deck Size Decks

Baking

Chambers

Thermostat

Range

Required

Clearances

Carton Dim

(W x H x D)

Cubic

Feet

Cubic

Meter

Ship

Wt.•

EB-1-8-3836

55" x 54" x 43"

(1397 x 1372 x 1092)

(203)

38" x 36"

(965 x 914)

1 1

150°-550°F

(65-288°C)

0" (0 mm)

60" x 48" x 24"

(1524 x 1219 x 610)

40 1.1

600

(273kg)

EB-2-8-3836

55" x 66" x 43"

(1397 x 1676 x 1092)

(203)

38" x 36"

(965 x 914)

2 2

150°-550°F

(65-288°C)

0" (0 mm) * * *

1200

(544kg)

EB-3-8-3836

55" x 66" x 43"

(1397 x 1676 x 1092)

(203)

38" x 36"

(965 x 914)

3 3

150°-550°F

(65-288°C)

0" (0 mm) * * *

1800

(819kg)

EB-1-8-5736

74" x 54" x 43"

(1880 x 1372 x 1092)

(203)

57" x 36"

(1448 x 914)

1 1

150°-550°F

(65-288°C)

0" (0 mm)

79" x 48" x 24"

(2007 x 1219 x 610)

40 1.1

700

(318kg)

EB-2-8-5736

74" x 66" x 43"

(1880 x 1676 x 1092)

(203)

57" x 36"

(1448 x 914)

2 2

150°-550°F

(65-288°C)

0" (0 mm) * * *

1500

(680kg)

EB-3-8-5736

74" x 66" x 43"

(1880 x 1676 x 1092)

(203)

57" x 36"

(1448 x 914)

3 3

150°-550°F

(65-288°C)

0" (0 mm) * * *

2250

(1021kg)

• Each oven ships in separate carton as do the legs. Refer to the single unit for shipping speciﬁcations. Shipping weight shown includes all decks and legs.

••Height includes 36" (914 mm) on single units, 30" (762 mm) legs on double units, and 12" (305 mm) on triple stacked units.

POWER SUPPLY

Model # Watts Voltage Phase Amps

L1 L2 L3 N

All 3836

models

8,000 208 3 25 25 29

8,000 220/240 3 22 22 28

8,000 208 1 39 39

8,000 220/240 1 35 35

8,000 230 1 35 35

8,000 440-480 3 12 12 14
