FEATURES AT A GLANCE
Bakers Pride
®
P48 series ovens feature two
independently controlled baking chambers, each with
one deck in your choice of Cordierite (7" height) or brick-
lined Cordierite (7.5" height). The greater deck height
allows you to accommodate taller bake and roast items.
The brick-lined model adds a Cordierite ceiling, which
offers the benet of increased temperature and recovery
time. They may be easily installed at the factory or in the
eld.
Each chamber has an independent thermostat and
60-minute electric timer with continuous-ring alarm
and manual shut-off. All models come standard
with stainless steel exterior and 4" adjustable legs.
International voltages are available.
SERIES: P48S & P48BL
HEARTHBAKE SERIES COUNTERTOP ELECTRIC OVENS
• 208 V or 220/240 V @ 4300 watts,
single or three phase
• Independent top and bottom
controlled incoloy heating
elements
• 150–550°F (65–288°C)
thermostat
• Two high-heat, aluminized steel
baking chambers
• Two 20.75" (527 mm) sq. decks
• 7.5" (191 mm) deck height or 7”
(178 mm) deck height with brick-
lined option
• Cordierite or brick-lined
• Two 60-minute, electric timers
with continuous-ring alarm and
manual shut-off
• All stainless steel exterior
• 6' (1829 mm) cord and plug on
single-phase units
• 4" (102 mm) adjustable legs
• Fully insulated
• One-year limited warranty
• Stainless steel stand with or without
casters
• International voltages
• Stacking kits
• Brick-lined conversion kit (standard
on P48BL)
• Steel decks
• Lightstone decks
OPTIONS & ACCESSORIES
www.bakerspride.com | p: 800.527.2100 265 Hobson St. • Smithville, TN 37166
2M-Z24638 REV-A (10-21)
EQUIPMENT DIMENSIONS
REQUIRED CLEARANCES
Left 3" (76 mm)
Right 3” (76 mm)
Back 3" (76 mm)
In European Community Countries and
North America. In NON-COMBUSTABLE
locations only.
In European Community Countries only in
COMBUSTIBLE locations. NOT for North
America.
MECHANICAL SPECIFICATIONS
Model # Overall Dim
(W x H x D)*
Deck
Height
Deck Size
(W x D)
Decks Baking
Chambers
Thermostat
Range
Carton Dim
(W x H x D)
Cubic
Feet
Cubic
Meter
Ship
Wt.
P48S
26" x 28.5" x 28"
(660 x 724 x 711)
7.5"
(191)
20.75" x 20.75"
(527 x 527)
2 2 150°-550°F
(66-288°C)
30" x 32" x 32"
(762 x 813 x 813)
17.7 .51 278
(126kg)
P48BL
26" x 28.5" x 28"
(660 x 724 x 711)
7"
(178)
20.75” x 20.75”
(527 x 527)
2 2 150°-550°F
(66-288°C)
30" x 32" x 32"
(762 x 813 x 813)
17.7 .51 288
(131kg)
*Height excludes legs
POWER SUPPLY
Model # Watts Voltage Phase Amps Plug Style
USA Canada UK Europe
P48S &
P28BL
4300 208 1, 3 20.7 6-30P
220/240 1, 3 18.7
SERIES: P48S & P48BL
HEARTHBAKE SERIES COUNTERTOP ELECTRIC OVENS
Freight Class: 110
FOB: Smithville 37166
6-30P
FRONT VIEW
400
350
300
250
200
150
450
500
550
°F
°C
80
100
120
140
160
180
200
220
240
260
280
400
350
300
250
200
150
450
500
550
°F
°C
80
100
120
140
160
180
200
220
240
260
280
MINUTES0
1
12
15
14
13
11
10
9
8
7
6
5
4
3
2
MINUTES0
1
12
15
14
13
11
10
9
8
7
6
5
4
3
2
BAKERS PRIDE
BAKERS PRIDE
26"
(660mm)
28.5"
(724mm)
SIDE VIEW/SECTION
21"
(533mm)
6.75"
(171mm)
9.5"
(241mm)
9.5"
(241mm)
7.5"
(190mm)
7.5"
(190mm)
11.5"
(292mm)
TOP VIEW
Bake Chamber
22 .25"
(565mm)
21 .75"
(552mm)
28"
(711mm)
1 .5"
(38mm)
Bakers Pride reserves the right to modify specications or discontinue
models without incurring obligation. Dimensions nominal.
www.bakerspride.com | p: 800.527.2100 265 Hobson St. • Smithville, TN 37166
