80162770
80162770
Push-button 2gang, + RGB LED, internal temp. sensor, KNX - K.1, p. white
Technical characteristics
Architecture
Fixing mode flush-mounting
Functions
With room temperature controller Yes
Easy link functions
operating concept "independent push-button"
function predefined, operating concept for "roller
shutter/blind" function predefined, switching of
scenes (1..8) possible, Orientation LED can be
controlled via object, brightness value of the status
LED for day/nighttime operation preset, status LED
for day/nighttime operation can be controlled via
object, integrated temperature sensor with output of
the measured values, Colour of status LED uniformly
adjustable for complete device, push-button
functions: including switching, dimming, roller
shutter/blind, timer, priority, temperature setpoint
adjustment, operating mode changeover
Function
Function for manual interruption of automatic
functions already triggered
Function
operating surfaces as buttons (single-surface
operation) and rockers (two-surface operation), the
brightness of status LEDs are individually adjustable
for button/ rocker function, brightness value of the
status LEDs for day/nighttime operation adjustable
via object or manually, value transmitter for
dimming, position, brightness temperature values 1
and 2 byte, button/rocker functions for switching,
dimming, roller shutter/blind, value transmitter 1/2
byte, room thermostat extension unit, priority,
scene, automatic control deactivation, integrated
temperature sensor with output of the measured
values via object, button functions for switching,
dimming, roller shutter/blind, timer, value
transmitter 1/2 byte, room thermostat extension
unit, priority, scene, 2-channel mode, step switch,
automatic control deactivation, rocker functions for
switching, dimming, roller shutter/blind, value
transmitter 1/2 byte, room thermostat extension
unit, priority, scene, 2-channel mode, automatic
control deactivation, 3-step switch, function for
incremental selection of up to 7 stored values,
Status LED configurable in its colour per button,
parameter defineable lock function
Controls and indicators
With LED indication Yes
Number of buttons 2
Operation
operating areas configurable as one or two-area
operation
Electric current
Bus current consumption (data transfer) max. 20 mA
Dimensions
Subject to technical modifications
Produktspecifikationer
| Varumärke: | Berker |
| Kategori: | Växla |
| Modell: | 80162770 |
| Bildsensortyp: | Temperatursensor |
| Modell: | Inbyggd |
| Uteffekt: | 150 mW |
| Temperatur mätenheter: | °C |
| Ändamål: | inomhus |
| Mätintervall för temperatur: | -5 - 45 ° C |
