80162773
80162773
Push-button 2gang, + RGB LED, internal temp. sensor, KNX - K.5, stainless steel
Technical characteristics
Architecture
Fixing mode flush-mounting
Functions
With room temperature controller Yes
Easy link functions
operating concept "independent push-button"
function predefined, operating concept for "roller
shutter/blind" function predefined, switching of
scenes (1..8) possible, Orientation LED can be
controlled via object, brightness value of the status
LED for day/nighttime operation preset, status LED
for day/nighttime operation can be controlled via
object, integrated temperature sensor with output of
the measured values, Colour of status LED uniformly
adjustable for complete device, push-button
functions: including switching, dimming, roller
shutter/blind, timer, priority, temperature setpoint
adjustment, operating mode changeover
Function
Function for manual interruption of automatic
functions already triggered
Function
operating surfaces as buttons (single-surface
operation) and rockers (two-surface operation), the
brightness of status LEDs are individually adjustable
for button/ rocker function, brightness value of the
status LEDs for day/nighttime operation adjustable
via object or manually, value transmitter for
dimming, position, brightness temperature values 1
and 2 byte, button/rocker functions for switching,
dimming, roller shutter/blind, value transmitter 1/2
byte, room thermostat extension unit, priority,
scene, automatic control deactivation, integrated
temperature sensor with output of the measured
values via object, button functions for switching,
dimming, roller shutter/blind, timer, value
transmitter 1/2 byte, room thermostat extension
unit, priority, scene, 2-channel mode, step switch,
automatic control deactivation, rocker functions for
switching, dimming, roller shutter/blind, value
transmitter 1/2 byte, room thermostat extension
unit, priority, scene, 2-channel mode, automatic
control deactivation, 3-step switch, function for
incremental selection of up to 7 stored values,
Status LED configurable in its colour per button,
parameter defineable lock function
Controls and indicators
With LED indication Yes
Number of buttons 2
Operation
operating areas configurable as one or two-area
operation
Electric current
Bus current consumption (data transfer) max. 20 mA
Dimensions
Subject to technical modifications
Labelling field length (W x H) 66.8 x 25 mm
Height 55.1 mm
Width 70.9 mm
Power
Power consumption, KNX ≈ 150 mW
Measurement
Value transmitter
value transmitter for dimming, position, brightness
and temperature values 1 and 2 byte
Screen
With display No
Materials
Colour of design line stainless steel
Colour stainless steel
RAL colour RAL 9022 - Pearl light grey
Material thermoplastic
Material for printing Paper
Surface appearance matt
Type of surface treatment Painted
Material family Plastic
LED control
LED
with white operating LED, with 2 RGB status LEDs
per rocker
Connection
Bus coupling unit for bus coupling unit flush-mounted
Settings
Supported configuration modes system, easy
Parameterisation
single and two push-button operation
parameterisable
Scope of delivery
Bus connection included No
Equipment
Number of actuation points 4
With anti-theft/dismantling protection Yes
Product type: product type: push-button 2gang
Use
Differentiation characteristic 1 - Sales with labelling fields
Differentiation characteristic 2 - Sales and RGB LED
Differentiation characteristic 3 - Sales with integrated temperature sensor
Safety
Protection index IP IP20
Halogen free No
Subject to technical modifications
Protection with dismantling protection
Alarm
alarm telegram after disconnection from bus
coupling unit 1 bit or 1 byte
Use conditions
Operating temperature -5…45 °C
Storage/transport temperature
-20…70 °C (storage at > 45°C reduces the service
life)
Temperature
integrated temperature sensor with output of the
measured values via object
Identification
Application, usage KNX - operating systems
Product family product family: push-button
Main design line KNX - Berker K.1/K.5
Secondary design line(s) KNX, Berker K.5
Instructions
Special note text
Use only in conjunction with bus coupling unit 8004
00 01!
Subject to technical modifications
