User’s Manual

SRP-330III/332III

THERMAL PRINTER

Ver. 1.00

http://www.bixolon.com

Ver. 1.00

- 2 -

SRP-330III/332III

Table of Contents

Copyright ........................................................................................................................... 3

WARNING & CAUTION ...................................................................................................... 7

Manual Introduction ........................................................................................................ 9

Product Introduction ..................................................................................................... 10

1. Content Confirmation ................................................................................................ 12

2. Product Part Names ................................................................................................... 13

2-1 Printer Part Names ......................................................................................................... 13

2-2 Interface Part Names ..................................................................................................... 14

2-2-1 USB Interface ...................................................................................................... 14

2-2-2 Ethernet Interface .............................................................................................. 15

2-2-3 Serial Interface (RS-232C) .................................................................................. 16

2-2-4 Parallel Interface (IEEE1284) ............................................................................. 18

2-2-5 Drawer Kick-out Cable ....................................................................................... 19

3. Installation & Usage ................................................................................................... 20

3-1 Printer Installation Placings .......................................................................................... 20

3-2 Power Connection .......................................................................................................... 21

3-3 Inserting and changing the paper roll ......................................................................... 23

3-4 Using Controller .............................................................................................................. 26

3-5 2-inch Mounting Partition .............................................................................................. 27

4. Self-Test ....................................................................................................................... 28

5. Hexadecimal Dumping ............................................................................................... 30

6. Maintenance ............................................................................................................... 31

6-1 Paper Jam......................................................................................................................... 31

6-2 Cleaning Printer .............................................................................................................. 32

7. Specifications .............................................................................................................. 33

7-1 Printer Specifications...................................................................................................... 33

7-2 Recommended Papers ................................................................................................... 34

Ver. 1.00

- 3 -

SRP-330III/332III

This user manual and all property of the product are protected under copyright law.

It is strictly prohibited to copy, store, and transmit the whole or any part of the manual

and any property of the product without the prior written approval of BIXOLON Co., Ltd.

The information contained herein is designed only for use with this BIXOLON product.

BIXOLON is not responsible for any direct or indirect damages, arising from or related to

use of this information.

• The BIXOLON logo is the registered trademark of BIXOLON Co., Ltd.

• All other brand or product names are trademarks of their respective companies or

organizations.

BIXOLON maintains ongoing efforts to enhance and upgrade the functions and quality of

all our products.

In the following, product specifications and/or user manual content may be changed

without prior notice.

Caution

Electronics, such as printers, are prone to damage by static electricity. Therefore, to

protect the printer from static electricity, be sure to turn off the printer before connecting

or disconnecting the cable to the rear of the printer. If the printer is damaged by static

electricity, contact your local dealer.

This euipmeqnt is not suitable for use in locations where children are likely to be present.

When the printer is operating with the media cover open, do not wear anything that can

touch the drive, such as clothing, necklaces, rings, watches, or employee certificates close

to it. Also, keep yourself away from the printer as it is dangerous for some parts of the

body to come into contact with it. If an object or part of your body touches the drive,

immediately disconnect the power cord or turn off the power switch on the back of the

product.
