Auteur MkII 500 | User Manual
Auteur MkII 500 | User Manual 2
Introduction ..........................................................................................................3
Features .................................................................................................................3
Specications ........................................................................................................ 3
Package Contents .................................................................................................4
Front .......................................................................................................................4
Connection Diagram ............................................................................................. 4
Signal Flow/Hardware Block Diagram ..................................................................5
Repair .....................................................................................................................5
Warranty ................................................................................................................5
Disclaimer ..............................................................................................................5
Copyright ...............................................................................................................6
TABLE OF CONTENTS
The Auteur MkII 500 is one of the most “bang for your buck” 500-series preamps in
existence! You get all of the sound of the ½ rack version, but with the addition of a Hi-Z
input! It features an ultra-fast input stage that captures lots of detail and nuance, and a
signal path transformer that adds some “beef” on the way out. Once you hear the Auteur
MkII 500, you’ll want to load your 500 rack full of ‘em!
INTRODUCTION
SPECIFICATIONS
Mic Section
• Max Microphone Input Level: +1dBu
• Input Impedance: 6000Ω
• Pad: 13dBu
• Gain (no pad): +16dB to +67dB
• Equivalent Input Noise (noise oor):
-108dB
• THD+N (@ +4dBu output):
• .0046% @ +12dBu Gain
• .0064% @ +24dBu Gain
• .012% @ +32dBu Gain
• .028% @ +40dBu Gain
• .085% @ +50dBu Gain
• .3% @ +62dBu Gain
• Bandwidth (1kHz, 600Ω
unbalancedsource, unweighted): 10Hz
to 30kHz
D.I. Section
• Max D.I. Input Level: +18dBu
• Input Impedance Balanced: 2.2MΩ
• Input Impedance Unbalanced: 1.1MΩ
• Pad: 13dBu
• Gain: +16dB to +67dB
• Equivalent Input Noise (noise oor):
-82dB
• THD+N:
• .011% @ +16dB Gain
• .024% @ +24dB Gain
• .15% @ +40dB Gain
• 2.2% @ +67dB Gain
• Bandwidth (1kHz, 600Ω
unbalancedsource, unweighted): 10Hz
to 30kHz
Output Section
• Max Output Level: +28dBu
• Output Impedance: 600Ω
Power Supply
• +/- 15v o 500 rack
Product Dimensions
• 1.5” x 6.5” x 5.25”
Product Weight
• .8 lbs
Shipping Dimensions
• 13” x 11” x 5”
Shipping Weight
• 1.8 lbs
FEATURES
• 500 Series format (500 rack required)
• Single Channel
• Ultra High-Speed Input Stage
• Edcor Output Transformer
• 67dB Gain
• Phantom Power
• Phase Switch
• 13dBu Pad
• Hi-Z Input
Auteur MkII 500 | User Manual 3
