Sida 1/7
Auteur Quad | User Manual
Introduction ..........................................................................................................3
Features .................................................................................................................3
........................................................................................................3
Package Contents .................................................................................................3
Front .......................................................................................................................4
Back .......................................................................................................................4
Connection Diagram .............................................................................................5
Signal Flow/Hardware Block Diagram ..................................................................5
Repair .....................................................................................................................6
Warranty ................................................................................................................6
Disclaimer ..............................................................................................................6
Copyright ...............................................................................................................7
TA B L E O F C O N T E N T S
2
Auteur Quad | User Manual
2
INTRODUCTION
SPECIFICATIONS
FEATURES
PACKAGE CONTENTS
How does one improve upon a mic preamp that already offers unbelievable sound at an
unbeatable price? Offer more of it! For the first time ever, the Auteur is now available in
a full width, 1U chassis, serving up 4 delicious channels of gain, 2 channels of Hi-Z input,
and 4 output meters to boot!
Using the same audio circuitry found in the Auteur MkII & Auteur MkII 500, the Auteur
Quad marries modern sound with vintage vibe by using a fast input stage to capture lots
of detail and nuance, then drives it through an output transformer for a little low-end
saturation. Once you get a taste of its polished sound and workhorse demeanor, all
you’ll want is more!
• Quad Channel
• Ultra High-Speed Input Stages
• Edcor Output Transformers
• 65dB Gain
• Extended Frequency Response
• Low Distortion & Noise
• Phantom Power
• Phase Switch
• 10dBu Pad
• XLR Microphone Inputs
• XLR & TRS Line Outputs
• Dual Front Panel Hi-Z Inputs
• LED Output Meters
Mic Section
• Max Microphone Input Level: +1dBu
• Input Impedance: 6000Ω
• Pad: 10dBu
• Gain (no pad): +14dB to +65dB
• Equivalent Input Noise (noise floor):
-108dB
• THD+N:
• .005% @ +14dB Gain
• .007% @ +24dB Gain
• .03% @ +40dB Gain
• .3% @ +65dB Gain
•
Bandwidth (1kHz, 150Ω source,unweighted):
10Hz to 30kHz
Output Section
• Max Output Level: +26dBu
• Output Impedance: 150Ω
Power Supply
•
+/- 21VDC, +51VDC External Power Supply
Product Dimensions
• 19"x6.9"x1.75"
Product Weight
• 7.8 lbs
Shipping Dimensions
• 27" x 10.5" x 4.5"
Shipping Weight
• 10 lbs
Auteur Quad | User Manual
• Auteur Quad
• Power Supply
3
