Sida 1/2
Block Transformatoren-Elektronik
GmbH
Max-Planck-Strasse 36-46
27283 Verden Germany
Phone: +49 4231 678 0 Fax: +49 4231 678 177
www.block-trafo.de sales@block-trafo.de
5
3
Gebrauchsanleitung
Einschaltstrombegrenzer
ESG 3 (Stecker/Kupplung: int. Typ F „Schuko“)
ESG 4 (Stecker/Kupplung: int. Typ G „BS1363/A“)
ESG 5
(Stecker/Kupplung: int. Typ B „NEMA5-15“)
Instruction Manual
Inrush Current Limiter
ESG 3 (plug/socket: int. Typ F „Schuko“)
ESG 4
(plug/socket: int. Typ G „BS1363/A“)
ESG 5 (plug/socket: int. Typ B „NEMA5-15“)
|
EN 61000-6-1
EN 61000-6-3
EN 61000-3-2
EN 61000-3-3
EN 60335-1
Made in Germany
Zeichnung-Nr. / Drawing-No.: Z710903004/d
Teile-Nr. / Part-No.: +1508-0144
Änderungen vorbehalten / subject to change without notice
6 7 8 1
Amendments
We have produced this documentation with the utmost care; how-
ever no guarantee in terms of correctness and completeness can
be given. The adoption of this information in an application must
be individually checked. The technical details describe the product
features without guaranteeing these. This product is subject to
changes that serve the technical advancement.
Description and Application
On physical condition, during power-up of certain loads, the auto-
matic circuit breaker or the motor circuit switch could shut off. The
Inrush Current Limiter prevents this. It can power-up and supply a
load up to max. 16A. The Inrush Current Limiter is insetted in the
load line. It has an intrinsic resistance (limiting resistance) of typ.
7.8 Ω, which is in series connection with the load. Therefore it can
flow an inrush current of max. 29.5A at 230Vac (because of the im-
pedances of mains and loads, the real inrush current is usually lo-
wer). Normally the switch-on peaks are decreased after some pe-
riods and the build-in power-relay bridges the intrinsic resistance of
the Inrush Current Limiter. Now the load is directly connected with
the mains. The Inrush Current Limiter operates mainly current-
leaded and partly time-leaded, i.e. the load current is continuously
controlled. Below a minimum load of typ. 20W, open-circuit is de-
tected and the limiting resistance is switched in the circuit perma-
nently. On higher wattage the limiting resistance is bridged; in this
case the inrush current cannot be limited. The period of inrush
current limiting is max. 300ms; depending on the load it will
reduced to min. 60ms. At the power-up moment of the Inrush
Current Limiter there is a defined limiting time of 150ms.
Standards
The requirements for CE conformity are given and the equipment
is CE marked.
Operation Information
The adequate cooling of the equipment should not be effected and
the air circulation must be guaranteed. Due to the protection index,
the use of the equipment is only permitted in dry areas.
Connection Information
The mains plug of the load must be connected via the Inrush Cur-
rent Limiter with the mains socket. For save operation a rated volt-
age not below 99Vac in the moment of turn-on the load is requir-
ed. More loss of voltage could cause an overload and would result
an irreparable damage to the Inrush Current Limiter by activating
the internal thermal fuse!
Connection
Before connection the Inrush Current Limiter to mains, check the
correct supply voltage (also see the marking on the equipment).
Fuse
The equipment is internally protected with a non-resettable thermal
fuse. If this fuse is switched off, with the utmost probability an un-
suitable mains supply is present (see Connection Information).
Technical Specification
Nominal Voltage 110…230Vac
Voltage range 99…253Vac
Nominal Frequency 50Hz...60Hz
Nominal Current ESG 3: up to 16A eff. *
ESG 4: up to 13A eff. *
ESG 5: up to 13A eff. *
* at max. +40°C ambient temperature
Intrinsic Resistance ESG 3: 7,8Ω ±5% *
ESG 4: 7,8Ω ±5% *
ESG 5: 4,4Ω ±5% *
* at the power-up moment
Switching Time bridging after approx. 60ms...300ms
(3...15 periods at 50Hz) depending on load
Connections ESG 3: 2x 1,3m power line cable
H05VV-F3G 1mm²
plug and socket: DIN49440;1
ESG 4: 2x 1,3m power line cable
H05VV-F3G 1mm²
plug and socket: BS1363
ESG 5: 2x 1,3m power line cable
SJT 3x16AWG (1,3mm²)
plug and socket: NEMA5-15
Construction encapsulated and resined
in an insulating housing
Protection Class I
Protection Index housing: IP65
plug/socket (ESG 3): IP44
plug/socket (ESG 4/5): IP20
Safety
●
build-in, non-exchangeable thermal fuse
in the load circuit
●
temperature controller bridges limiting
resistance at overload
●
resin acc. UL 94 V-0
Housing Dimensions Length: 121mm *
Width: 66mm *
Height: 70mm *
* without the two power line cables
Weight approx. 750g
with the two power line cables
Safety and User Information
Congratulations to the ownership of this high quality product. A
long life expectancy is assured if used in the described manner
and correct application. As with all technical products, a hazard
to health or equipment can exist if improperly used, an un-
authorized removal of necessary covers, an incorrect in-
stallation or an incorrect operation is present. Follow these in-
structions and adhere to the generally accepted rules of tech-
nology. Installation and setting-up should only be carried out by
qualified personal (IEC 60364 / VDE 0105).
Packing
Please check carefully the equipment immediately after receipt,
for transport damage as deformation, breakage or loose parts.
Any damage should be reported without delay to the transport
carrier, even if no apparent damage to external packing is vi-
sible.
Storage
Permitted Storage Temperature -25°C...+85°C
Permitted Humidity 30%...80% relative humidity
Residual humidity is not per-
mitted.
Extended Storage Equipment containing capa-
citors: should be connected
to the mains supply for at
least 5 minutes every two
years.
Installation and Operation
This equipment is protected against improper use. The contact
with electrical components and terminals should be avoided.
The product description, the technical information in our main
catalogue and the marking on the equipment are to be ob-
served. The installation must be carried out according to the
prevailing local conditions, prevailing safety standards (e.g.
VDE 0100), national accident preventions (e.g. UVV-VBG 4;
BGV A2 respectively) and the generally accepted rules of tech-
nology.
Maintenance and Servicing
This equipment usually requires no special maintenance, how-
ever (depending on the protection index) it must be protected
against aggressive chemicals, moisture, dust and radiation.
Servicing is only permitted under the terms and conditions of
these operating instructions. Nevertheless should a failure
occur, please return the equipment to us for repair. Please give
us the following information: Type of fault, accompanying symp-
toms (operating conditions), your own speculation upon the
cause of the failure, previous unusual conditions, etc.
Disposal
Please observe the current regulations and dispose according
to type of material, e.g. as electronic scrap (printed circuit
boards), plastics (housing), steel, copper, etc.
